James D Hitchens

US Patent:

6752281, Jun 22, 2004

Filed:

Mar 20, 2003

Appl. No.:

10/392597

Inventors:

Timothy L. Mason - Melville NY
James D. Hitchens - Islip Terrace NY

Assignee:

New Dimensions Research Corporation - Melville NY

International Classification:

A47F 500

US Classification:

211195, 211163, 2111311, 2111331, 312135

Abstract:

A display device for displaying articles of merchandise, such as books and posters, is provided. The display device has four rectangular support structures. Each support structures includes a base, a first side wall, a second side wall, a first door hinged to the first side wall, a second door hinged to the second side wall, a back wall, and a cover hinged to the back wall. Each side wall is hinged to a side wall of an adjoining one of the support structures. At least one wheel is connected to the base of each support structure. The display device is movable between an open position wherein the back walls of the support structures define an enclosed space and a closed position wherein the back walls of each support structure faces the back wall of an adjoining one of the support structures.

US Patent:

D489198, May 4, 2004

Filed:

Apr 2, 2003

Appl. No.:

29/178970

Inventors:

Timothy L. Mason - Melville NY 11747
James D. Hitchens - Islip Terrace NY 11752

International Classification:

0604

US Classification:

D 6461
