Allan B Kirby

US Patent:

43975160, Aug 9, 1983

Filed:

May 26, 1981

Appl. No.:

6/267159

Inventors:

David H. Koren - Sidney NY
Allan B. Kirby - Sidney Center NY
Donald H. Gould - Sidney NY

Assignee:

The Bendix Corporation - Southfield MI

International Classification:

H01R 1708

US Classification:

339177R

Abstract:

A cable termination apparatus (90) for use in locating and terminating an electrical cable (10) of the twin-axial type to an electrical connector (50), the cable having a pair of insulated wires (20,30) having inner conductors (22, 32), the apparatus being characterized by as comprising a body (91) of conductive material including a passage (95) for receiving and locating one of the wires (30) and a radial slot (96) for receiving and locating the inner conductor (22) of the other wire (20), the passage (95) extending through the body and having a generally frusto-conical wire entry portion, (97) the slot (96) extending axially inward from one end of the body and intersecting with the frusto-conical portion (97) to provide stress relief to the conductor (22) when terminated within the slot (96) by solder (98).

US Patent:

44444532, Apr 24, 1984

Filed:

Oct 2, 1981

Appl. No.:

6/308061

Inventors:

Allan B. Kirby - Sidney Center NY
Geoffrey P. Johnson - Movato CA

Assignee:

The Bendix Corporation - Southfield MI

International Classification:

H01R 1718

US Classification:

339177R

Abstract:

An electrical connector (60) is disclosed of the type to which a coaxial cable (22) having a braided conductor layer (26) is adapted to be clamped to establish electrical and mechanical connections, characterized by a simplified cable clamping means. The clamping means includes an outer contact-clamping body (72) formed with a clamping cone (112) integral with an outer contact portion (68). In preferred embodiments, the contact-clamping body (72) is engagable to be held against rotation by flats (94) formed on the outside diameter of an intermediate section (93) thereof, connector coupling sleeve (62) movable into mating engagement therewith, and to be retracted to allow the coupling sleeve (62) to be rotatable during coupling with a mating connector.
