Andrea O Barney

US Patent:

6652950, Nov 25, 2003

Filed:

Feb 6, 2002

Appl. No.:

10/072793

Inventors:

Andrea Barney - Bedford MA
Charles A Whittington - Gardena CA
Bryan Eilertson - Huntington Beach CA
Zenon Siminski - Bellflower CA

Assignee:

The Boeing Company - Chicago IL

International Classification:

B32B 522

US Classification:

428102, 442262, 428902, 428905

Abstract:

The conformal thermal insulating blanket may have generally rigid batting material covered by an outer insulating layer formed of a high temperature resistant woven ceramic material and an inner insulating layer formed of a woven ceramic fiber material. The batting and insulating layers may be fastened together by sewing or stitching using an outer mold layer thread fabricated of a high temperature resistant material and an inner mold layer thread of a ceramic fiber material. The batting may be formed to a composite structure that may have a firmness factor sufficient to inhibit a pillowing effect after the stitching to not more than 0. 03 inch. The outer insulating layer and an upper portion of the batting adjacent the outer insulating layer may be impregnated with a ceramic coating material.

US Patent:

6770584, Aug 3, 2004

Filed:

Aug 16, 2002

Appl. No.:

10/222651

Inventors:

Andrea O. Barney - Bedford MA
Vann Heng - Buena Park CA
Kris Shigeko Oka - Huntington Beach CA
Maryann Santos - Los Angeles CA
Alfred A. Zinn - Huntington Beach CA
Michael Droege - Livermore CA

Assignee:

The Boeing Company - Seattle WA

International Classification:

C04B 3580

US Classification:

501 951, 501 952, 501 87, 4282934, 4282937, 428478, 442 77, 442140, 442178, 264640, 264643

Abstract:

A hybrid insulation material comprises of porous ceramic substrate material impregnated with nanoporous material and method of making the same is the topic of this invention. The porous substrate material has bulk density ranging from 6 to 20 lb/ft and is composed of about 60 to 80 wt % silica (SiO ) 20 to 40 wt % alumina (Al O ) fibers, and with about 0. 1 to 1. 0 wt % boron-containing constituent as the sintering agent. The nanoporous material has density ranging from 1. 0 to 10 lb/ft and is either fully or partially impregnated into the substrate to block the pores, resulting in substantial reduction in conduction via radiation and convention. The nanoporous material used to impregnate the fiber substrate is preferably formed from a precursor of alkoxysilane, alcohol, water, and an acid or base catalyst for silica aerogels, and from a precursor of aluminum alkoxide, alcohol, water, and an acid or base catalyst for alumina aerogels.

US Patent:

20030022983, Jan 30, 2003

Filed:

Jul 23, 2001

Appl. No.:

09/911194

Inventors:

Andrea Barney - Waltham MA, US
Claire Anton - Los Alamitos CA, US
John Crumpler - Long Beach CA, US
John Jones - Anaheim CA, US
Bryan Brewer - Laguna Hills CA, US

International Classification:

C08J003/00

US Classification:

524/588000

Abstract:

A highly abrasion resistant and durable, low density ablator composition is provided that comprises a base silicone resin, silica microballoons as a filler, a catalyst, and a thinning fluid to control the viscosity of the base silicone resin. The density of the resulting composition is approximately 0.32 g/cc yet the composition has excellent abrasion resistance. Furthermore, the ratio of filler to base silicone resin, by weight, is approximately 0.91. The ablator composition is also RF (radio frequency) transparent, moisture resistant, and low cost. Methods of mixing the ablator composition and forming ablative structures are also provided.

US Patent:

20090068441, Mar 12, 2009

Filed:

Aug 29, 2008

Appl. No.:

12/231177

Inventors:

Srinivas H. Swaroop - Acton MA, US
Timothy D. Davis - Tewksbury MA, US
Andrea O. Barney - Bedford MA, US

International Classification:

B32B 5/16
C09K 5/14

US Classification:

428329, 252 75, 252 74

Abstract:

The present invention relates to thermal interface materials comprising a filler dispersed in a polymer, wherein the filler has an average aggregate particle size of less than or equal to 1 micron. Preferably the filler is a synthetic alumina, such as fumed alumina.

US Patent:

20140190672, Jul 10, 2014

Filed:

Mar 13, 2014

Appl. No.:

14/210141

Inventors:

- Boston MA, US
Timothy D. Davis - Tewksbury MA, US
Andrea O. Barney - Bedford MA, US

Assignee:

Cabot Corporation - Boston MA

International Classification:

F28F 13/18

US Classification:

165133, 252 783, 252 75

Abstract:

The present invention relates to thermal interface materials comprising a filler dispersed in a polymer, wherein the filler has an average aggregate particle size of less than or equal to 1 micron. Preferably the filler is a synthetic alumina, such as fumed alumina.
