Barry Noel Rodgers

US Patent:

6944176, Sep 13, 2005

Filed:

Oct 11, 2000

Appl. No.:

09/686178

Inventors:

Scott Brown - Wake Forest NC, US
Brad Peabody - Raleigh NC, US
Gary Pollard - Wendell NC, US
Milton Hotard - Knightdale NC, US
Rod Washington - Raleigh NC, US
Barry Rodgers - Raleigh NC, US

Assignee:

Square D Company - Palatine IL

International Classification:

H04L012/40
H04L012/50

US Classification:

370438, 370362

Abstract:

A system and method for data table multiplexing on a serial multiplex data (bit level) system is described. The present invention combines the benefits of previous systems with the capability to transfer large tables of data. The method used to transfer this data is a software data multiplexing protocol that utilizes the previous physical layer protocol and is capable of coexisting with previous systems. Multiple bit addresses are assigned functions such as address, data, and error detection. This establishes a data transfer frame that is used to multiplex data between a host and a module. Communication to and from the host is accomplished through the register map. The register map contains module setup information, software configuration settings, raw data, or summary data.

US Patent:

7680561, Mar 16, 2010

Filed:

Sep 14, 2006

Appl. No.:

11/520904

Inventors:

Barry Noel Rodgers - Raleigh NC, US
Andy Allen Haun - Raleigh NC, US
Robert Joseph Dwulet - Wake Forrest NC, US
Mark John Kocher - Raleigh NC, US
Julius Michael Liptak - Knightdale NC, US
Alexander Filippenko - Cary NC, US
Scott Robert Brown - Wake Forrest NC, US
Gary Myron Kuzkin - Raleigh NC, US
Gary W. Scott - Mount Vernon IA, US

Assignee:

Schneider Electric USA, Inc. - Palatine IL

International Classification:

G05B 11/01

US Classification:

700295, 34031011, 34031016

Abstract:

An intelligent power management system that includes a circuit breaker containing a PLC module that spans open contacts of the circuit breaker to provide a communication path for PLC messages between communication paths on each of the line and load sides of the circuit when the contacts are open. The contacts are motorized to permit remote operation through PLC messaging. Coupled to the PLC module is a controller, which controls the opening and closing of the motorized contacts under user control or via an adaptive load management algorithm that reduces peak power consumption and adapts a set of loads to changed power supply conditions. The controller can also dynamically alter operational current and fault threshold levels on a real-time basis based upon circuit requirements or environmental conditions. The algorithm runs a state machine and also manages loads in a limited power source environment such as when loads are powered by a generator.

US Patent:

8576521, Nov 5, 2013

Filed:

Aug 16, 2011

Appl. No.:

13/210943

Inventors:

Barry Rodgers - Raleigh NC, US
Henry Patrick - Raleigh NC, US

Assignee:

Schneider Electric USA, Inc. - Palatine IL

International Classification:

H02H 9/08

US Classification:

361 42

Abstract:

A controller-based detection system configured to adaptively learn to distinguish between detected light that is indicative of an arc fault event and detected light that is not related to an arc fault event. In particular, the detection system is configured to observe the electrical power system as it is operated under various conditions to induce light events that are unrelated to arc fault events. Using the observed information about the light events that are unrelated to arc fault events, the detection system determines one or more detection algorithms. During normal operation of the electrical power system, the adaptively determined one or more detection algorithms are utilized to identify arc fault events in the electrical power system.

US Patent:

20050116814, Jun 2, 2005

Filed:

Oct 25, 2004

Appl. No.:

10/972508

Inventors:

Barry Rodgers - Raleigh NC, US
Andy Haun - Raleigh NC, US
Robert Dwulet - Wake Forrest NC, US
Mark Kocher - Raleigh NC, US
Julius Liptak - Knightdale NC, US
Alexander Filippenko - Cary NC, US
Scott Brown - Wake Forrest NC, US
Gary Kuzkin - Raleigh NC, US
Gary Scott - Mount Vernon IA, US

International Classification:

H02H005/04

US Classification:

340310010

Abstract:

An intelligent power management system that includes a circuit breaker containing a PLC module that spans open contacts of the circuit breaker to provide a communication path for PLC messages between the line and load sides of the circuit when the contacts are open. The contacts are motorized to permit remote operation through PLC messaging. Coupled to the PLC module is a controller, which controls the opening and closing of the motorized contacts under user control or via an adaptive load management algorithm that reduces peak power consumption and adapts a set of loads to changed power supply conditions. The controller can also dynamically alter operational current and fault threshold levels on a real-time basis based upon circuit requirements or environmental conditions. The algorithm runs a state machine and also manages loads in a limited power source environment such as when loads are powered by a generator.

US Patent:

20070010916, Jan 11, 2007

Filed:

Sep 14, 2006

Appl. No.:

11/520900

Inventors:

Barry Rodgers - Raleigh NC, US
Andy Haun - Raleigh NC, US
Robert Dwulet - Wake Forrest NC, US
Mark Kocher - Raleigh NC, US
Julius Liptak - Knightdale NC, US
Alexander Filippenko - Cary NC, US
Scott Brown - Wake Forrest NC, US
Gary Kuzkin - Raleigh NC, US
Gary Scott - Mount Vernon IA, US

International Classification:

H02J 3/00

US Classification:

700295000

Abstract:

An intelligent power management system that includes a circuit breaker containing a PLC module that spans open contacts of the circuit breaker to provide a communication path for PLC messages between the line and load sides of the circuit when the contacts are open. The contacts are motorized to permit remote operation through PLC messaging. Coupled to the PLC module is a controller, which controls the opening and closing of the motorized contacts under user control or via an adaptive load management algorithm that reduces peak power consumption and adapts a set of loads to changed power supply conditions. The controller can also dynamically alter operational current and fault threshold levels on a real-time basis based upon circuit requirements or environmental conditions. The algorithm runs a state machine and also manages loads in a limited power source environment such as when loads are powered by a generator.

US Patent:

55657850, Oct 15, 1996

Filed:

Nov 18, 1994

Appl. No.:

8/342191

Inventors:

Barry Rodgers - Raleigh NC
Stanley H. Edwards - Raleigh NC
Timothy B. Phillips - Raleigh NC

Assignee:

Square D Company - Palatine IL

International Classification:

G01R 3500

US Classification:

324601

Abstract:

A calibration method for a potentiometer which provides indicia reflecting an accurate indication of actual electrical resistance throughout the resistive range of a particular potentiometer. The indicia includes a number of graduation marks or symbols having a range and spacing unique to the resistive characteristics of the particular potentiometer. The indicia is fixed with respect to a known location associated with the particular potentiometer. The range and spacing of the indicia graduations is derived from measured resistance values at predetermined locations along the resistive member of the particular potentiometer.

US Patent:

56686927, Sep 16, 1997

Filed:

Oct 27, 1993

Appl. No.:

8/143948

Inventors:

Barry Noel Rodgers - Raleigh NC
Timothy Brian Phillips - Raleigh NC

Assignee:

Square D Company - Palatine IL

International Classification:

H02H 318
H02H 902

US Classification:

361 93

Abstract:

A circuit interrupter arrangement for interrupting current in a circuit path includes a hysteresis control circuit arranged to control a power supply charge-accumulation switch and an undervoltage trip-lockout circuit in parallel. More specifically, the arrangement includes a current inducer circuit for inducing a current signal having a magnitude corresponding to the current in the circuit path; an energy accumulator for accumulating a magnitude of energy to cause an interruption of the circuit path; an energy accumulator control circuit controlling the magnitude of energy accumulating; a trip lock-out circuit, responsive to an insufficient magnitude of accumulated energy, for preventing an interruption of the circuit path; and a range control circuit, responsive to the current inducer circuit, for operating a power-related signal between a first level and a second level to control the energy accumulator control circuit and the trip lock-out circuit.

US Patent:

57743193, Jun 30, 1998

Filed:

Nov 15, 1995

Appl. No.:

8/558310

Inventors:

Michael Baron Carter - Clayton NC
Roger Alan Plemmons - Raleigh NC
Barry Noel Rodgers - Raleigh NC
Timothy Brian Phillips - Raleigh NC
George Marshall Horne - Cary NC

Assignee:

Square D Company - Palatine IL

International Classification:

H02H 300

US Classification:

361 93

Abstract:

A self-powered circuit interrupter arrangement for interrupting current in a circuit path uses a current-blocking component to ensure that an insufficient amount of accumulated power for actuating and completing interruption of the circuit path is not misused in an unwarranted attempt to interrupt the current path. The arrangement includes a current inducer circuit for providing a current signal having a magnitude corresponding to the current in the circuit path and a power supply operating from the current signal to provide a voltage signal of a predetermined value relative to common. A trip command circuit, in response to a fault detected in the circuit path, sends an electrical signal commanding that the circuit path be interrupted by using the voltage signal. The electrical signal is sent to an electrical latch located electrically in series with a coil of a solenoid mechanism. Current from the power supply passing through the coil of a solenoid mechanism causes the interruption of current in the current path.
