Anand Chandran

US Patent:

7798122, Sep 21, 2010

Filed:

Sep 4, 2008

Appl. No.:

12/204091

Inventors:

Anand Chandran - Springfield IL, US
Al Cable - Springfield IL, US
Bindu Philip - Bangalore, IN
Rick Holzmacher - Springfield IL, US
Gangl Rajula Reddy - Bangalore, IN
Shakil Moonamkandy - Bangalore, IN
Ravindra Gudi - Bangalore, IN

Assignee:

Honeywell International Inc. - Morristown NJ

International Classification:

F02D 11/10
F02D 11/04

US Classification:

123399, 123400

Abstract:

A drive-by-wire throttle control apparatus and method includes a variable resistance sensor. A contact arm can be mechanically connected between a thumb lever and a variable resistance sensor. The variable resistance sensor possesses a resistive film that includes a fixed resistor and a variable resistor configured from a carbon film. As the thumb lever rotates, the contact arm traverses the resistive film, thereby altering the resistance of the variable resistor, determining the position of the thumb lever and thereafter generating a signal based on the sensed position. The signal can be sent to an ECU (Electronic Control Unit) in the form of a varying voltage, which in turn controls the throttle of a vehicle.

US Patent:

D671847, Dec 4, 2012

Filed:

Feb 29, 2012

Appl. No.:

29/414515

Inventors:

Anand Chandran - Dunlap IL, US
Robert Richard Brimble - Edwards IL, US
Linda Kay Waible - Peoria IL, US

Assignee:

Robert Bosch GmbH - Stuttgart

International Classification:

1007

US Classification:

D10 40

US Patent:

D671848, Dec 4, 2012

Filed:

Feb 29, 2012

Appl. No.:

29/414516

Inventors:

Anand Chandran - Dunlap IL, US
Robert Richard Brimble - Edwards IL, US
Linda Kay Waible - Peoria IL, US

Assignee:

Robert Bosch GmbH - Stuttgart

International Classification:

1007

US Classification:

D10 40

US Patent:

D671849, Dec 4, 2012

Filed:

Feb 29, 2012

Appl. No.:

29/414520

Inventors:

Anand Chandran - Dunlap IL, US
Robert Richard Brimble - Edwards IL, US
Linda Kay Waible - Peoria IL, US

Assignee:

Robert Bosch GmbH - Stuttgart

International Classification:

1003

US Classification:

D10 40, D10122

US Patent:

20100038166, Feb 18, 2010

Filed:

Aug 12, 2008

Appl. No.:

12/190361

Inventors:

Anand Chandran - Springfield IL, US
Al Cable - Springfield IL, US
Rick Holzmacher - Springfield IL, US
Nurul Hasan, I - Bodinayakanur, IN
Shakil Moonamkandy - Bangalore, IN
Gangi Rajula Reddy - Bangalore, IN
Ravindra Gudi - Bangalore, IN

International Classification:

B60K 13/00

US Classification:

180335

Abstract:

A drive by wire contactless throttle control which includes a contactless Hall-effect magnetic sensor. The Hall-effect magnetic sensor can be located in a mounting bracket in contactless association with a thumb lever on a handle bar. A magnet can be placed in a slot inside the thumb lever with a bonder and filled with an epoxy. The Hall-effect magnetic sensor senses the magnetic field produced by the magnet as the thumb lever rotates and determines position of the thumb lever and generates a signal based on the sensed position. The signal can be sent to an ECU (Electronic Control Unit) utilizing electrical wires in the form of varying voltage, which in turn controls throttle of a vehicle, such as an all terrain vehicle, snowmobile, etc.

US Patent:

20100043589, Feb 25, 2010

Filed:

Aug 20, 2008

Appl. No.:

12/194760

Inventors:

Anand Chandran - Springfield IL, US
Al Cable - Springfield IL, US

International Classification:

G05G 1/08

US Classification:

74504

Abstract:

A drive-by-wire throttle control apparatus and method of forming the same. The apparatus includes a Hall-effect magnetic sensor. A thumb lever can be assembled into a mounting bracket inside a cylindrical hole, which can rotate to a desired angle. The thumb lever can be mechanically connected to a magnet holder, which includes a magnet, utilizing a key-slot mechanism. The magnet holder can be placed inside a housing that allows the magnet holder to rotate and restrict other movements. When the thumb lever rotates, the lever rotates the magnet holder, which in turn detects the position of the throttle utilizing a varying voltage output from an associated Hall-effect chip. A signal can be generated based on the sensed position.

US Patent:

20100182017, Jul 22, 2010

Filed:

Jan 21, 2009

Appl. No.:

12/356680

Inventors:

Gangi Rajula Reddy - Bangalore, IN
Anand Chandran - Springfield IL, US
Al Cable - Springfield IL, US
Richard Alan Holzmacher - Springfield IL, US
Ravindra Gudi - Bangalore, IN
Deepak Murali - Bangalore, IN
Shakil Moonamkandy - Bangalore, IN

International Classification:

G01R 27/26
H01G 7/00
G06F 19/00

US Classification:

324662, 29 2541, 701101

Abstract:

A drive-by-wire non-contact capacitive throttle control apparatus and method of forming the same. A capacitive position sensor is provided, which includes a stationary electrode and a rotatable electrode. The rotatable electrode can be attached to a throttle lever such that the rotatable electrode rotates as the throttle lever rotates. The capacitance between the rotatable electrode and the stationary electrode varies with the position of the throttle lever. The position of the throttle lever can be measured by measuring the capacitance between the electrodes and a signal can be generated based on the sensed position. The signal can be electrically transmitted to an ECU (Electronic Control Unit) utilizing one or more electrical wires. The signal can be sent in the form of a varying voltage, which in turn controls the throttle of a vehicle.
