Charles F Simmers

US Patent:

8339058, Dec 25, 2012

Filed:

Nov 23, 2009

Appl. No.:

12/623657

Inventors:

Charles R. Simmers - Phoenix AZ, US

Assignee:

Microchip Technology Incorporated - Chandler AZ

International Classification:

H05B 41/16

US Classification:

315246, 315152, 315250

Abstract:

Perceived output color and intensity (brightness) of light from a three-element red-green-blue (RGB) light emitting diode (LED) or optical combination of three LEDs (red, green and blue) are controlled with three pulse train signals, each having fixed pulse width and voltage amplitude and then increasing or decreasing the frequency (increasing or decreasing the number of pulses over a time period) of these pulse train signals so as to vary the average current through each of the RGB-LEDs. This reduces the level of electro-magnetic interference (EMI) at any one frequency by varying the pulse train energy spectrum over a plurality of frequencies.

US Patent:

8339068, Dec 25, 2012

Filed:

Oct 9, 2009

Appl. No.:

12/576346

Inventors:

Charles R. Simmers - Phoenix AZ, US

Assignee:

Microchip Technology Incorporated - Chandler AZ

International Classification:

G06F 1/00
H05B 37/02
H05B 39/04
H05B 41/36

US Classification:

315297, 315158, 315291

Abstract:

Perceived intensity (brightness) of light from a light emitting diode (LED) is controlled with a pulse train signal having fixed pulse width and voltage amplitude and then increasing or decreasing the frequency (increasing or decreasing the number of pulses over a time period) of this pulse train signal so as to vary the average current through the LED. This reduces the level of electro-magnetic interference (EMI) at any one frequency by varying the pulse train energy spectrum over a plurality of frequencies.

US Patent:

20020144235, Oct 3, 2002

Filed:

Mar 30, 2001

Appl. No.:

09/822739

Inventors:

Charles Simmers - Phoenix AZ, US
Joseph Triece - Phoenix AZ, US

International Classification:

G06F009/44

US Classification:

717/124000

Abstract:

An embedded system is provided with the capability to be debugged. The embedded system includes a central processing unit (CPU) that is coupled to a bus having certain contents. A register, also with contents, is available for loading by the CPU. Finally, a debug logic circuit is also included. The debug logic circuit is coupled to both the bus and the CPU. The debug circuit itself is composed of a breakpoint detect circuit that is coupled to the bus and to the register. This circuitry enables a breakpoint signal that is produced by the breakpoint detect circuit when the contents of the register equal the contents of the bus. A method is also provided for debugging an embedded system having a microcontroller with a CPU. First, a debug logic circuit that resides on the same chip as the microcontroller is programmed to detect a predetermined condition in the microcontroller. Next, application software is run on the microcontroller. When a predetermined condition is detected, the CPU is interrupted which provides the ability to view the condition of the microcontroller. Programming the debug logic circuit can include the storing of a breakpoint address in a breakpoint address register. Afterward, a program memory address bus is selected for comparison to the contents of the breakpoint address register, upon which time a breakpoint counter is set to zero. The steps of interrupting and detecting are accomplished by comparing the contents of the program memory address bus to the contents of the breakpoint register and, if they are equal, then the CPU is interrupted.

US Patent:

59073306, May 25, 1999

Filed:

Dec 18, 1996

Appl. No.:

8/768427

Inventors:

Charles R. Simmers - Phoenix AZ

Assignee:

Intel Corporation - Santa Clara CA

International Classification:

G09G 500

US Classification:

345512

Abstract:

A method and apparatus for reducing power consumption and system bus load caused by a display controller in a unified memory system. A compression engine monitors a bus over which display data from the unified memory flows. The compression engine captures and compresses a copy of the display data corresponding to a display frame. The compressed data is stored in a small memory unit. Subsequent refreshes of the display are serviced by a decompression engine. The decompression engine decompresses the compressed data from the small memory unit and provides the decompressed data to the display controller.

US Patent:

60755237, Jun 13, 2000

Filed:

Jan 26, 1999

Appl. No.:

9/237575

Inventors:

Charles R. Simmers - Phoenix AZ

Assignee:

Intel Corporation - Santa Clara CA

International Classification:

G06T 900

US Classification:

345202

Abstract:

A method and apparatus for reducing power consumption and system bus load caused by a display controller in a unified memory system. A compression engine monitors a bus over which display data from the unified memory flows. The compression engine captures and compresses a copy of the display data corresponding to a display frame. The compressed data is stored in a small memory unit. Subsequent refreshes of the display are serviced by a decompression engine. The decompression engine decompresses the compressed data from the small memory unit and provides the decompressed data to the display controller.

US Patent:

58414312, Nov 24, 1998

Filed:

Nov 15, 1996

Appl. No.:

8/749486

Inventors:

Charles Russell Simmers - Phoenix AZ

Assignee:

Intel Corporation - Santa Clara CA

International Classification:

G09G 500
G09G 336
G06F 100
G06F 116

US Classification:

345211

Abstract:

An apparatus for conserving power in information devices with dual functions. A single display panel is logically split into two sub-panels. Each sub-panel can be powered up or down separately as is required by the function of the device. The display panel has a plurality of improved segment drivers which are provided power signals enabling the set of segment drivers corresponding to a sub-panel to be separately powered. In systems with two separate display panels, each of the panels may be powered up or down by the use of similar improved segment drivers as necessary.
