Daniel Alan Beall

US Patent:

6585246, Jul 1, 2003

Filed:

Jun 22, 2001

Appl. No.:

09/887293

Inventors:

Peter Elliott McCormick - Dallas TX
Daniel Alan Beall - Allen TX
Detlev Ulle - Reichelsheim, DE

Assignee:

Delaware Capital Formation, Inc. - Wilmington DE

International Classification:

B25B 104

US Classification:

269239, 269 32, 269228, 269 24, 269 27

Abstract:

An electrically powered clamp has a housing, a motor attached to the housing, a ball screw driven by the motor via gears, and a linkage driven at one end by the ball screw such that the linkage rotates an output shaft attached to the other end of the linkage. The motor and gears drive the ball screw to a fully extended position to rotate the shaft to a clamped position or to a fully retracted position to rotate the shaft to an unclamped position. A built-in computer monitors and controls the clamp. The clamp can also be controlled and monitored by a remote pendant. Indicator lights on the housing and remote pendant convey clamp status information. The clamp is programmable and can memorize the clamped and unclamped positions. The clamp uses velocity and position feedback to determine appropriate drive mode. Torque monitors and timers determine if the clamp becomes stuck.

US Patent:

6883795, Apr 26, 2005

Filed:

Aug 13, 2003

Appl. No.:

10/640200

Inventors:

Peter E. McCormick - Dallas TX, US
Daniel Alan Beall - Allen TX, US

Assignee:

Delaware Capital Formation, Inc. - Wilmington DE

International Classification:

B25B001/04
B25B005/04

US Classification:

269239, 269225, 269 32

Abstract:

An electrically powered clamp has a housing, a motor attached to the housing, a ball screw driven by the motor via a belt, and a linkage driven at one end by the ball screw such that the linkage rotates an output shaft attached to the other end of the linkage. The motor and belt drive the ball screw between a fully extended position to rotate the shaft to a clamped position, and a fully retracted position to rotate the shaft to an unclamped position. A built-in computer monitors and controls the clamp. The clamp can also be controlled and monitored by a remote pendant. Indicator lights on the housing and remote pendant convey clamp status information. The clamp is programmable and can memorize the clamped and unclamped positions. The clamp uses velocity and position feedback to determine appropriate drive mode. Torque monitors and timers determine if the clamp becomes stuck.

US Patent:

7000911, Feb 21, 2006

Filed:

Feb 26, 2004

Appl. No.:

10/788142

Inventors:

Peter E. McCormick - Dallas TX, US
Daniel Alan Beall - Allen TX, US

Assignee:

Delaware Capital Formation, Inc. - Wilmington DE

International Classification:

B25B 1/04

US Classification:

269239, 269 32, 269 20

Abstract:

A motor pack for an electrically driven tool includes at least one electric motor and a linearly displaceable member coupled to the electric motor such that the linearly displaceable member is displaced axially by operation of the at least one electric motor. The motor pack further includes a housing enclosing the electric motor and at least partially enclosing the linearly displaceable member. The housing includes a front plate to which a tool head may be removably coupled. The front plate has an aperture formed therein through which the linearly displaceable element can be coupled to a moveable element in the tool head. The motor pack also includes tool control circuitry enclosed within the housing and electrically coupled to the electric motor to control operation thereof.

US Patent:

7121539, Oct 17, 2006

Filed:

Oct 8, 2005

Appl. No.:

11/245716

Inventors:

Peter E. McCormick - Dallas TX, US
Daniel Alan Beall - Allen TX, US

Assignee:

Delaware Capital Formation, Inc. - Wilmington DE

International Classification:

B25B 1/04

US Classification:

269239, 269 32, 269228

Abstract:

A motor pack for an electrically driven tool includes at least one electric motor and a linearly displaceable member coupled to the electric motor such that the linearly displaceable member is displaced axially by operation of the at least one electric motor. The motor pack further includes a housing enclosing the electric motor and at least partially enclosing the linearly displaceable member. The housing includes a front plate to which a tool head may be removably coupled. The front plate has an aperture formed therein through which the linearly displaceable element can be coupled to a moveable element in the tool head. The motor pack also includes tool control circuitry enclosed within the housing and electrically coupled to the electric motor to control operation thereof.

US Patent:

8169377, May 1, 2012

Filed:

Apr 6, 2009

Appl. No.:

12/418757

Inventors:

Larry Jack Tippit - Arlington TX, US
Daniel Alan Beall - Allen TX, US
Julian Patrick Moore - Sachse TX, US

Assignee:

ASC Signal Corporation - Smithfield NC

International Classification:

H01Q 1/12
H01Q 3/08

US Classification:

343757, 343766

Abstract:

A pointing apparatus and method of operation for an antenna mount provided with a base frame and an antenna mount rotatably coupled together. A first wheel rigidly coupled to one of the base frame and the antenna mount driven by a mechanical linkage with a first drive wheel and a second drive wheel mounted to the base frame or the antenna mount not rigidly coupled to the first wheel. The first drive wheel and the second drive wheel driven against one another in opposite directions; a torque level unbalance applied between the first motor and the second motor operative to rotate the base frame and the antenna mount with respect to one another in a first desired direction.

US Patent:

20110050526, Mar 3, 2011

Filed:

Aug 31, 2009

Appl. No.:

12/550956

Inventors:

Daniel Alan Beall - Allen TX, US

Assignee:

ASC Signal Corporation - Smithfield NC

International Classification:

H01Q 3/12

US Classification:

343761

Abstract:

A thermal compensating subreflector tracking assembly for a reflector antenna and methods of use. The subreflector tracking assembly provided with a base, an intermediate support and a subreflector mount. The intermediate support coupled to the base, movable normal to the base and the subreflector mount coupled to the intermediate support, movable orthogonal to the intermediate support. The movement in the Z, Y and or Z-axis enabling electrical performance optimizing reflector antenna beam alignment and/or focus adjustments resulting from asymmetric thermal distortion of the reflector antenna.

US Patent:

63189267, Nov 20, 2001

Filed:

Feb 10, 2000

Appl. No.:

9/501878

Inventors:

David Silvas - Wylie TX
Daniel Beall - Allen TX
Richard Schulze - Plano TX

Assignee:

EOA Systems Incorporated - Dallas TX

International Classification:

B25G 300
F16B 300
F16D 100

US Classification:

403345

Abstract:

A pivot bearing comprises a shaped bar having an outer circumferential surface provided with two oppositely arranged, longitudinally extending notches, and a sleeve arranged on the shaped bar and having an externally cylindrical surface and an inner circumferential surface facing the outer circumferential surface of the shaped bar and provided with two oppositely arranged longitudinally extending notches. The longitudinally extending notches of the shaped bar are in alignment with the longitudinally extending notches of the sleeve to form two pairs of notches, and cylindrical pins are arranged in the two pairs of notches.
