David Douglas Haynes

US Patent:

59314834, Aug 3, 1999

Filed:

Feb 9, 1998

Appl. No.:

9/020686

Inventors:

David Lee Haynes - Kemah TX

International Classification:

B62B 112

US Classification:

280 4719

Abstract:

A foldable-unfoldable bowling caddy has two spaced apart, parallel, generally vertically extending support legs mounted on wheels. A series of spaced apart flat forward racks rotatable to and from a folded position aligned with the two parallel legs to and from an unfolded horizontal position are attached to the two parallel legs. A third leg is pivotally connected to the two parallel legs and is movable to and from a folded position adjacent the two parallel legs to and from an angular position that forms a tripod with the two parallel legs. A rear rack is also connected to the two parallel legs and is rotatable to and from a folded position extending along the plane of the two parallel legs to and from an unfolded horizontally extending position. The third leg is releasably pinned to the rear rack when both are in their unfolded positions. A swivel ball is attached to the lower end of the third leg.
