Dennis J Fesler

US Patent:

51218313, Jun 16, 1992

Filed:

Jan 8, 1990

Appl. No.:

7/462061

Inventors:

Dennis J. Fesler - Des Peres MO

Assignee:

Carondelet Foundry Company - St. Louis MO

International Classification:

B65G 1706

US Classification:

198853

Abstract:

An improved link for a grate conveyor or the like, which is an elongate casting having at a first end thereof a pair of transversely spaced side walls and at the other or second end thereof a lug having a width generally corresponding to the width of the space between said walls and extending out endwise at said second end. The lug is adapted to fit between the spaced side walls of the next link in a series of links making up the chain. The side walls have aligned holes therein of circular cross section coaxial on a first axis extending transversely of the link adjacent its first end. The lug also has a hole therein of circular cross section on a second axis extending transversely of the link adjacent its second end wherein the second axis is parallel to the first axis. The link is cast of a metallic material and has inserts of a harder material extending partially around the circumference of each of the holes in said side walls at that side of each of those holes toward the first end of the link and an insert of a harder material extending partially around the circumference of the hole in the lug at that side of the hole toward the second end of the link.

US Patent:

54397510, Aug 8, 1995

Filed:

Dec 30, 1993

Appl. No.:

8/175996

Inventors:

Dennis J. Fesler - Des Peres MO

Assignee:

Carondelet Foundry Company - Pevely MO

International Classification:

B32B 1518
B65G 1706

US Classification:

428614

Abstract:

An improved cast grate cooler side plate having a bottom surface containing a metal alloy insert embedded therein wherein said insert is formed from an alloy selected from the group consisting of: A. an alloy consisting essentially of, by weight, ______________________________________ Carbon about 1. 5-3% Chromium about 23-30% Manganese
