Dimitri N Stinaroff

US Patent:

6622684, Sep 23, 2003

Filed:

Mar 14, 2003

Appl. No.:

10/389178

Inventors:

Dimitri Stinaroff - Bayside NY 11364
Diana Stinaroff - Bayside NY 11364

International Classification:

F02N 300

US Classification:

1231884, 123 81 B, 123 51 A

Abstract:

An intake and exhaust system for an internal combustion engine having a unitary engine block the system comprising a power cylinder, an intake lifter cylinder and an exhaust lifter cylinder that are formed integral with the engine block. This engine block has an intake port, and an exhaust port for allowing exhaust to flow there through. Inside the piston or power cylinder is a power piston which is driven by a crank shaft connected by connecting rod which extends through the power cylinder. This crank shaft is driven by a movement of the power piston which is caused by combustion of gasses inside the engine block. There is also a cam shaft which disposed within the engine block. This cam shaft is found on a top section of the engine block. Coupled to the cam shaft is a timing chain which is also coupled to said crank shaft. Thus, as the crank shaft rotates, it drives the timing chain which in turn rotates said cam shaft.
