Francis J Hebert

US Patent:

44362358, Mar 13, 1984

Filed:

Jun 8, 1982

Appl. No.:

6/386311

Inventors:

Francis A. Hebert - Schriever LA

Assignee:

South Louisiana Contractors Inc. - Lafayette LA

International Classification:

B25C 102

US Classification:

227111

Abstract:

My invention is directed to portable pneumatic nail driving devices for working with large nails ranging in size from 30 to 90 penny which are fed from a primary chute through a transfer chute to a nail driving barrel carried by a base frame. Upstanding from the base are guides over which slides a cradle to which a pneumatic gun having a chisel is carried to that the chisel enters the barrel after a nail has been introduced to drive the nail. Such apparatus is used in the construction of board roads in swamps incident to oil field work.

US Patent:

44334648, Feb 28, 1984

Filed:

Aug 28, 1981

Appl. No.:

6/297102

Inventors:

Francis A. Hebert - Schriever LA

Assignee:

South Louisiana Contractors - Lafayette LA

International Classification:

B23P 1904

US Classification:

29252

Abstract:

An apparatus for salvaging nailed boards employed in the building of temporary board roads over marsh land. The boards have nails extending from one side thereof which must be bent flush and the boards stacked in bundles for reuse in laying a new board road. The apparatus has at its front end a set of board receiving rolls with their axes along the major axis of the machine for receiving the boards with their major axis transversely of the machine on the rolls with the nail extending upwardly. Co-extensive with the board receiving rolls for advancing the boards edgewise from the front to the rear of the machine are pivoted dog pushers. In advance of the nail bending roll there is provided a pair of barriers for maintaining a single vertical layer of boards. A pair of endless chains are positioned to engage and move boards edgewise rearwardly from the board receiving rolls through the machine. A single large rotary nail bending roll is positioned diagonally across the machine with its rotary axis extending across at least four boards simultaneously is positioned rearwardly of the barriers.

US Patent:

45496820, Oct 29, 1985

Filed:

Jun 13, 1983

Appl. No.:

6/503551

Inventors:

Francis A. Hebert - Schriever LA

Assignee:

Soloco, Inc. - Lafayette LA

International Classification:

B25C 102

US Classification:

227119

Abstract:

The present disclosure is directed to a nail driving apparatus having a percussive air hammer driving a chisel. The apparatus has a base member, having guide means upstanding from each side of the base member. A cradle means is movable along the guide means and means carried by the cradle means is adapted to mount the air hammer securely to said cradle means. A nail barrel means is carried by the base member into which both nails to be driven and the chisel of the air hammer is positioned on the base member to be received and one of the guide means upstanding from the base member forms a nail chute having means for delivering nails singly to the barrel means beneath the chisel when the air hammer and cradle is raised. A nail chute transfer means is positioned to receive nails from a nail chute in one of the guide means and to direct nails into the nail barrel means through the intermediary of an antijamming chamber between said transfer chute and chisel causing a nail fed from said transfer chute means to be pivoted and hung by its head out of the way of the chisel until the chisel is raised clear of contact with the nail head permitting the nail to drop into the barrel in position to be driven by the chisel.

US Patent:

46535950, Mar 31, 1987

Filed:

Aug 28, 1985

Appl. No.:

6/770200

Inventors:

Francis A. Hebert - Schriever LA

Assignee:

Soloco, Inc. - Lafayette LA

International Classification:

B25D 706

US Classification:

173128

Abstract:

The present disclosure is directed to a hammer and follow block chain remote release device and method to eliminate the need of a human having to ride the pile driving leads until the follow block is separated from the hammer. This is attained by passing a chain through the follow block and over horns on the hammer. A remote release device is connected to one end of the chain and an elongated link secured to the other end of the chain is engaged with the release device and a remotely actuated coupling member is pulled to release the connection between the chain and release device to permit separation of the follow block from the hammer by passage of the chain through the follow block and over the horns on the hammer.
