Frank E Peters

US Patent:

6771682, Aug 3, 2004

Filed:

Oct 30, 2002

Appl. No.:

10/283476

Inventors:

Frank H. Peters - San Jose CA

Assignee:

Infinera Corporation - Sunnyvale CA

International Classification:

H01S 500

US Classification:

372 50, 372 45

Abstract:

Electrical isolation regions are formed between adjacently disposed electro-optical components integrated in a monolithic semiconductor photonic chip, such as an EML or PIC chip. A bias, V , is applied to the isolation region so that any parasitical current path developed between adjacent active or passive optical components, now separated by an isolation region, is established through the electrical isolation region and clamped to the bias, V. The applied bias, V , may be a positive bias, a negative bias, or a zero or a ground bias. The electrical isolation regions are formed by spatial current blocking regions formed at adjacent sides of the electrical isolations region transverse to a direction of light propagation through the optical components, or between the electrical isolation regions and adjacent optical components. The spatial current blocking regions may be comprised of a pair of spatially disposed trenches or ion implanted regions or high resistance implanted regions.

US Patent:

6804271, Oct 12, 2004

Filed:

Nov 6, 2001

Appl. No.:

10/011503

Inventors:

Ken Nishimura - Fremont CA
Scott Corzine - Sunnyvale CA
Frank H. Peters - San Jose CA
Gary Gordon - Saratoga CA

Assignee:

Agilent Technologies, Inc. - Palo Alto CA

International Classification:

H01S 310

US Classification:

372 27, 372 43, 372 44, 372 45, 372 46, 372 47, 372 48, 372 49, 372 50, 372 99, 372105

Abstract:

Light emission methods and light emission devices are described including method and devices capable of emitting light at a plurality of controllable wavelengths. According to one aspect, a light emission method includes providing a control signal and emitting light using a laser operating in a plurality of polarization states. The polarization state of the laser is adjusted responsive to the control signal and the wavelength of the light emitted using the laser is adjusted responsive to the adjustment of the polarization state of the laser.

US Patent:

6839370, Jan 4, 2005

Filed:

Dec 31, 2001

Appl. No.:

10/040167

Inventors:

Frank H. Peters - San Jose CA, US
Michael H. Leary - Fremont CA, US
Yoon-Kyu Song - San Jose CA, US

Assignee:

Agilent Technologies, Inc. - Palo Alto CA

International Classification:

H01S 500

US Classification:

372 46, 372 45

Abstract:

An optoelectronic device such as a vertical cavity surface emitting laser (VCSEL) includes a tunnel junction that conducts a current of holes tunneling into an active region. Tunneling in a selected area of the tunnel junction is disabled to form a current blocking region that confines the current to desired regions. Tunneling can be disabled in the selected area using techniques including but not limited to implanting or diffusing dopants, disrupting crystal structure, or etching to remove part of the tunnel junction.

US Patent:

6922422, Jul 26, 2005

Filed:

Oct 30, 2002

Appl. No.:

10/283475

Inventors:

Frank H. Peters - San Jose CA, US
Radhakrishnan L. Nagarajan - Cupertino CA, US

International Classification:

H01S003/04

US Classification:

372 36, 372 34, 372 50, 385 14

Abstract:

Photonic integrated circuits (PIC) semiconductor chips are provided with thermal isolation and/or heat dissipation structures between integrated optical components in the PIC chip, particularly integrated active optical components. These structures may also serve as a ground path for electrical circuitry on the PIC chip. An important function is the enhanced thermal isolation from, or dissipation of heat from, between adjacent or neighboring optical components in the PIC so that required spacing between adjacent optical components can be made even less than the thickness of the substrate thereby realizing a more compact optical component array on the monolithic PIC chips.

US Patent:

6999489, Feb 14, 2006

Filed:

Mar 24, 2004

Appl. No.:

10/807729

Inventors:

Frank H. Peters - San Jose CA, US

Assignee:

Infinera Corporation - Sunnyvale CA

International Classification:

H01S 5/00

US Classification:

372 50, 372 45

Abstract:

A method of electrically isolating and operating electro-optical components integrated in a monolithic semiconductor photonic chip, such as an EML or PIC chip. A bias, V, is applied to the isolation region so that any parasitical current path developed between adjacent active or passive optical components, now separated by an isolation region, is established through the electrical isolation region and clamped to the bias, V. The applied bias, V, may be a positive bias, a negative bias, or a zero or a ground bias. The electrical isolation regions are formed by spatial current blocking regions formed at adjacent sides of the electrical isolations region transverse to a direction of light propagation through the optical components, or between the electrical isolation regions and adjacent optical components. The spatial current blocking regions may be comprised of a pair of spatially disposed trenches or ion implanted regions or high resistance implanted regions.

US Patent:

7006719, Feb 28, 2006

Filed:

Mar 10, 2003

Appl. No.:

10/385574

Inventors:

Charles H. Joyner - Sunnyvale CA, US
Mark J. Missey - San Jose CA, US
Radhakrishnan L. Nagarajan - Cupertino CA, US
Frank H. Peters - San Jose CA, US
Mehrdad Ziari - Pleasanton CA, US

Assignee:

Infinera Corporation - Sunnyvale CA

International Classification:

G02B 6/10
G02B 6/12

US Classification:

385 14, 385129

Abstract:

Disclosed are apparatus and methods of reducing insertion loss, passivation, planarization and in-wafer testing of integrated optical components and in-wafer chips in photonic integrated circuits (PICs).

US Patent:

7027703, Apr 11, 2006

Filed:

Dec 21, 2004

Appl. No.:

11/018149

Inventors:

Charles H. Joyner - Sunnyvale CA, US
Mark J. Missey - San Jose CA, US
Radhakrishnan L. Nagarajan - Cupertino CA, US
Frank H. Peters - San Jose CA, US
Mehrdad Ziari - Pleasanton CA, US

Assignee:

Infinera Corporation - Sunnyvale CA

International Classification:

G02B 6/10
C23F 1/00

US Classification:

385129, 385 14, 385 37, 385132, 65429, 216 2, 216 24

Abstract:

A method for forming and apparatus comprising a free space coupler region having a plurality of optical waveguides coupled to the space coupler region at an interface region, the waveguides converging with one another to the interface region, and a trench formed between adjacent waveguides, the depth of the trench or trenches extending from an outer point to the interface region and monotonically decreasing in depth from the outer point to the interface region.

US Patent:

7049570, May 23, 2006

Filed:

Sep 16, 2002

Appl. No.:

10/245632

Inventors:

Kit M. Cham - Cupertino CA, US
Frank H. Peters - San Jose CA, US

Assignee:

Avago Technologies, Ltd. - Singapore

International Classification:

G01J 1/20

US Classification:

2502011, 385 18

Abstract:

An optical communication system including an integrated circuit chip, an electro-optical chip operatively integrated on the integrated circuit chip, an adjustable optical chip which includes at least one optical element disposed between the electro-optical chip and one of a source or recipient of at least one optical signal, at least one micromachine operatively coupled to the at least one optical element to selectively manipulate the at least one optical element; an optical signal sensor disposed relative to the at least one optical signal to sense an optical signal condition data, and to transmit said optical signal condition data to the integrated circuit chip, a feedback circuit between the integrated circuit chip and the at least one micromachine, the integrated circuit chip configured to receive the optical signal condition data, convert it to a corresponding feedback signal, and to transmit the feedback signal through the feedback circuit to the micromachine, thereby causing the micromachine to selectively manipulate the at least one optical element to alter the optical signal.
