Fredrick Oluoch Onyango

US Patent:

8576129, Nov 5, 2013

Filed:

May 10, 2012

Appl. No.:

13/468733

Inventors:

Jimmie Paul Partee - Double Oak TX, US
Carlos Valmonte Jimenez - Keller TX, US
Fredrick Oluoch Onyango - Keller TX, US

International Classification:

H01Q 1/00

US Classification:

343703, 3405721, 324628

Abstract:

A test fixture for performing RF testing. The test fixture includes a base plate configured to support an electronic device. The base plate defines a grid of grooves. The base plate further defines a cut-out configured to receiving an antenna in one or more positions. The test fixture further includes markers indicating positioning of the electronic device on the base plate.

US Patent:

20110102275, May 5, 2011

Filed:

Nov 5, 2009

Appl. No.:

12/613293

Inventors:

Jimmie Paul Partee - Double Oak TX, US
Carlos Valmonte Jimenez - Kellar TX, US
Fredrick Oluoch Onyango - Keller TX, US

International Classification:

G01R 29/08

US Classification:

343703

Abstract:

A system and method for testing RF characteristics of a wireless device. The wireless device is placed on a base plate of a test fixture. One or more guides are positioned for securing the wireless device. At least one RF antenna is positioned. The position of the wireless device and the at least one RF antenna coupler relative to each other corresponds to acceptable RF characteristics for testing the wireless device. Positions of the one or more guides and the RF antenna coupler are identified. The identified positions are utilized to subsequently test similar wireless devices.

US Patent:

20110102276, May 5, 2011

Filed:

Nov 5, 2009

Appl. No.:

12/613324

Inventors:

Carlos Valmonte Jimenez - Keller TX, US
Jimmie Paul Partee - Double Oak TX, US
Fredrick Oluoch Onyango - Keller TX, US

International Classification:

G01R 29/08

US Classification:

343703

Abstract:

A system and method for testing RF characteristics of a wireless device. The wireless device is positioned in an x-position and a y-position of a horizontal plane of a test fixture. An RF antenna coupler is positioned in an x-position and a y-position of a vertical plane. The positioning of the wireless device and the RF antenna coupler correspond to acceptable RF characteristics for testing the wireless device. Positions of the wireless device and the RF antenna coupler are identified. The identified positions are utilized to perform subsequent testing of similar wireless devices.

US Patent:

20130321222, Dec 5, 2013

Filed:

Aug 8, 2013

Appl. No.:

13/962385

Inventors:

Carlos Valmonte Jimenez - Keller TX, US
Fredrick Oluoch Onyango - Keller TX, US

Assignee:

ATC Logistics & Electronics, Inc. - Fort Worth TX

International Classification:

G01R 29/10

US Classification:

343703

Abstract:

One embodiment provides a system, method, and test fixture for performing RF testing of an electronic device. An RF antenna is received in a base plate. One or more guides are positioned on the base plate for securing the electronic device above the RF antenna. The electronic device is secured on the base plate to perform the RF testing utilizing the one or more guides.

US Patent:

20140049433, Feb 20, 2014

Filed:

Oct 28, 2013

Appl. No.:

14/064764

Inventors:

Carlos Valmonte Jimenez - Keller TX, US
Fredrick Oluoch Onyango - Keller TX, US

Assignee:

ATC Logistics & Electronics, Inc. - Fort Worth TX

International Classification:

G01R 29/10

US Classification:

343703

Abstract:

A method for performing RF testing of an electronic device. An RF antenna is received in a base plate. The base plate defines a grid of grooves. One or more guides are received for connection to the base plate for securing the electronic device above the RF antenna. The electronic device is secured on the base plate utilizing the one or more guides to perform the RF testing.

US Patent:

20140071001, Mar 13, 2014

Filed:

Nov 1, 2013

Appl. No.:

14/070248

Inventors:

Jimmee Paul Partee - Double Oak TX, US
Fredrick Oluoch Onyango - Keller TX, US

Assignee:

ATC Logistics & Electronics, Inc. - Fort Worth TX

International Classification:

G01R 29/10

US Classification:

343703

Abstract:

A system and method for testing RF characteristics of a wireless device. The wireless device is positioned in an x-position and a y-position of a horizontal plane of a test fixture. An RF antenna coupler is positioned in an x-position and a y-position of a vertical plane. The positioning of the wireless device and the RF antenna coupler correspond to acceptable RF characteristics for testing the wireless device. Positions of the wireless device and the RF antenna coupler are identified. The identified positions are utilized to perform subsequent testing of similar wireless devices.

US Patent:

20160370426, Dec 22, 2016

Filed:

Aug 30, 2016

Appl. No.:

15/251890

Inventors:

- Fort Worth TX, US
Jimmee Paul PARTEE - Double Oak TX, US
Fredrick Oluoch ONYANGO - Keller TX, US

International Classification:

G01R 31/302
G01R 1/04
G01R 31/28

Abstract:

A system for testing radio frequency (RF) characteristics of a wireless device includes a test fixture. The test fixture includes a base plate that receives a wireless device, and a back plate that receives an RF antenna and positions the RF antenna relative to the wireless device. Additionally, the system includes test equipment that in operation performs RF testing on the wireless device using the RF antenna to determine RF characteristics of the wireless device.

US Patent:

20140361937, Dec 11, 2014

Filed:

Aug 25, 2014

Appl. No.:

14/467713

Inventors:

- Fort Worth TX, US
Carlos Valmonte Jimenez - Keller TX, US
Fredrick Oluoch Onyango - Keller TX, US

International Classification:

G01R 29/10

US Classification:

343703

Abstract:

One embodiment provides a system, method, and test fixture for performing RF testing of an electronic device. An RF antenna is received in a base plate. One or more guides are positioned on the base plate for securing the electronic device above the RF antenna. The electronic device is secured on the base plate to perform the RF testing utilizing the one or more guides.
