George H Prinz

US Patent:

20100275541, Nov 4, 2010

Filed:

Apr 30, 2010

Appl. No.:

12/799784

Inventors:

George Prinz - Saugerties NY, US

Assignee:

Unity Creations, Ltd. - Saugerties NY

International Classification:

E04B 5/00
E04B 5/48
E04C 2/20

US Classification:

523021, 525881, 523093

Abstract:

A tile for covering an area and which interlocks with an adjacent tile includes a main body having a top surface and a bottom surface disposed opposite the top surface. The main body has at least a first lateral side and a second lateral side. The tile includes at least one male connector situated on at least one of the first lateral side and the second lateral side of the main body and extending outwardly therefrom. The tile further includes at least one female receptacle situated on at least one of the first lateral side and the second lateral side of the main body and extending outwardly therefrom. The male connector of the tile is engageable with a female receptacle of an adjacent tile so that the tile may interlock with the adjacent tile.

US Patent:

20120124925, May 24, 2012

Filed:

Nov 14, 2011

Appl. No.:

13/295816

Inventors:

George H. Prinz - Saugerties NY, US
Bruce Washburn - Rhinebeck NY, US
Erick B. Prinz - Huntington NY, US

Assignee:

UNITY CREATIONS, LTD. - Saugerties NY

International Classification:

E04B 5/48
E04B 5/00

US Classification:

523021, 525881

Abstract:

A tile for covering an area which interlocks with an adjacent tile includes a main body having a top surface and a bottom surface disposed opposite the top surface. The main body has at least a first lateral side and a second lateral side. The tile includes a plurality of spaced apart male connectors situated on the first lateral side, and a plurality of spaced apart female receptacles situated on the second lateral side. The tile further includes a plurality of spaced apart slots and a plurality of spaced apart projections. Each slot is situated on either the first lateral side or the second lateral side of the main body inbetween either adjacent male connectors or adjacent female receptacles. Similarly, each projection is situated either on the first lateral side or the second lateral side of the main body inbetween either adjacent female receptacles or adjacent male connectors. The male connectors of the tile are engageable with female receptacles of an adjacent tile so that the tile may interlock with the adjacent tile. Also, the projections of the tile are receivable by slots of the adjacent tile to help prevent the tiles from curling or separating.
