Hanzhong Zhang

US Patent:

7232363, Jun 19, 2007

Filed:

Sep 16, 2004

Appl. No.:

10/942600

Inventors:

Hanzhong Zhang - Cupertino CA, US
Feng Liu - San Jose CA, US
Stan Tsai - Fremont CA, US
Rashid Mavliev - Campbell CA, US
Donald Olgado - Palo Alto CA, US
Liang-Yuh Chen - Foster City CA, US

Assignee:

Applied Materials, Inc. - Santa Clara CA

International Classification:

B24B 57/02
B24B 7/22

US Classification:

451 41, 451 60, 451446

Abstract:

A substrate polishing apparatus and method are described. A base includes at least one movable platen to engage a polishing pad. At least one carrier head assembly presses a substrate against the polishing pad substantially within a polishing area during a polishing operation. A polishing solution dispenser applies a polishing solution to the polishing pad substantially within the polishing area during the polishing operation. A polishing solution retaining mechanism is attached to one of the base or the carrier head assembly. The retaining mechanism engages a top surface of the polishing pad and retains the polishing solution substantially within the polishing area during the polishing operation. Some implementations may reduce polishing solution consumption and allow for increased angular velocity.

US Patent:

20100212358, Aug 26, 2010

Filed:

Feb 26, 2009

Appl. No.:

12/393875

Inventors:

DHRUV GAJARIA - Sunnyvale CA, US
Hanzhong Zhang - Cupertino CA, US
Richard Hong - San Jose CA, US

Assignee:

Applied Materials, Inc. - Santa Clara CA

International Classification:

C03B 20/00

US Classification:

65 2912, 65158

Abstract:

The present disclosure relates to methods for automated inspection of the orientation of a glass substrate () having a side that is coated and/or impregnated with a non-glass material (e.g., tin). One method () includes: picking up the glass substrate () by using an automatic lifting assembly (); inspecting a side of the glass substrate () with a sensor () so as to determine whether the inspected side is coated or impregnated with the non-glass material; determining whether the glass substrate () is correctly oriented based upon the inspection results; and using the automated lifting assembly () to place the glass substrate () on a conveyor () in response to determining that the glass substrate () is correctly oriented.

US Patent:

20110209746, Sep 1, 2011

Filed:

Sep 3, 2010

Appl. No.:

12/875725

Inventors:

Hanzhong Zhang - Santa Clara CA, US
Jian Li - Fremont CA, US

International Classification:

H01L 31/048
H01L 31/0203
H01L 31/18

US Classification:

136251, 136259, 118723 E, 438 57, 257E31001

Abstract:

A tubular photovoltaic device capable of collecting light from a variety of angles is disclosed. The tubular photovoltaic device is sealed at an end with a sealing ring and hermetic sealing cap. Novel deposition electrodes and processes for depositing thin films inside a tubular substrate are also disclosed.
