Howard D Haynes

US Patent:

6941785, Sep 13, 2005

Filed:

May 13, 2003

Appl. No.:

10/437630

Inventors:

Howard D. Haynes - Knoxville TN, US
Daryl F. Cox - Knoxville TN, US
Donald E. Welch - Oak Ridge TN, US

Assignee:

UT-Battelle, LLC - Oak Ridge TN

International Classification:

B21D039/08

US Classification:

72 57, 417 4411, 318799

Abstract:

A pump diagnostic system and method comprising current sensing probes clamped on electrical motor leads of a pump for sensing only current signals on incoming motor power, a signal processor having a means for buffering and anti-aliasing current signals into a pump motor current signal, and a computer having a means for analyzing, displaying, and reporting motor current signatures from the motor current signal to determine pump health using integrated motor and pump diagnostic parameters.

US Patent:

7071841, Jul 4, 2006

Filed:

Aug 19, 2004

Appl. No.:

10/922023

Inventors:

Howard D. Haynes - Knoxville TN, US
Alfred Akerman - Knoxville TN, US
Curtis W. Ayers - Kingston TN, US

Assignee:

UT-Battelle, LLC - Oak Ridge TN

International Classification:

G08G 1/04
G08G 1/052
G08G 1/054
G08G 1/056

US Classification:

340943, 701119, 367127, 73587

Abstract:

A passive vehicle acoustic data analyzer system having at least one microphone disposed in the acoustic field of a moving vehicle and a computer in electronic communication the microphone(s). The computer detects and measures the frequency shift in the acoustic signature emitted by the vehicle as it approaches and passes the microphone(s). The acoustic signature of a truck driving by a microphone can provide enough information to estimate the truck speed in miles-per-hour (mph), engine speed in rotations-per-minute (RPM), turbocharger speed in RPM, and vehicle weight.

US Patent:

7717826, May 18, 2010

Filed:

Mar 21, 2007

Appl. No.:

11/688893

Inventors:

Daryl F. Cox - Knoxville TN, US
Charles D. Hochanadel - Oak Ridge TN, US
Howard D. Haynes - Knoxville TN, US

Assignee:

UT-Battelle, LLC - Oak Ridge TN

International Classification:

A63B 71/00
A61B 5/22
A61B 5/103

US Classification:

482 8, 7337904, 738654, 600587, 600592

Abstract:

The invention is a human and animal performance data acquisition, analysis, and diagnostic system for fitness and therapy devices having an interface box removably disposed on incoming power wiring to a fitness and therapy device, at least one current transducer removably disposed on said interface box for sensing current signals to said fitness and therapy device, and a means for analyzing, displaying, and reporting said current signals to determine human and animal performance on said device using measurable parameters.

US Patent:

7736273, Jun 15, 2010

Filed:

Mar 10, 2009

Appl. No.:

12/401139

Inventors:

Daryl F. Cox - Knoxville TN, US
Charles D. Hochanadel - Oak Ridge TN, US
Howard D. Haynes - Knoxville TN, US

Assignee:

UT-Battelle, LLC - Oak Ridge TN

International Classification:

A63B 71/00
A61B 5/22
A61B 5/103

US Classification:

482 8, 7337904, 738654, 600587, 600592

Abstract:

The invention is a human and animal performance data acquisition, analysis, and diagnostic system for fitness and therapy devices having an interface box removably disposed on incoming power wiring to a fitness and therapy device, at least one current transducer removably disposed on said interface box for sensing current signals to said fitness and therapy device, and a means for analyzing, displaying, and reporting said current signals to determine human and animal performance on said device using measurable parameters.

US Patent:

7881882, Feb 1, 2011

Filed:

Sep 25, 2006

Appl. No.:

11/526970

Inventors:

Lonnie C. Maxey - Knoxville TN, US
Howard D. Haynes - Knoxville TN, US

Assignee:

UT-Battelle, LLC - Oak Ridge TN

International Classification:

G08B 13/00

US Classification:

702 42, 702 57, 340562, 340566

Abstract:

A system for monitoring or detecting tampering in a flexible structure includes taking electrical measurements on a sensing cable coupled to the structure, performing spectral analysis on the measured data, and comparing the spectral characteristics of the event to those of known benign and/or known suspicious events. A threshold or trigger value may used to identify an event of interest and initiate data collection. Alternatively, the system may be triggered at preset intervals, triggered manually, or triggered by a signal from another sensing device such as a motion detector. The system may be used to monitor electrical cables and conduits, hoses and flexible ducts, fences and other perimeter control devices, structural cables, flexible fabrics, and other flexible structures.

US Patent:

54873029, Jan 30, 1996

Filed:

Feb 28, 1995

Appl. No.:

8/396092

Inventors:

Donald A. Casada - Knoxville TN
Howard D. Haynes - Knoxville TN
John C. Moyers - Oak Ridge TN
Brian K. Stewart - Burns TN

Assignee:

Lockheed Martin Energy Systems, Inc. - Oak Ridge TN

International Classification:

F16K 3700

US Classification:

73168

Abstract:

Valve clearances and seating force, as well as other valve operational parameters, are determined by measuring valve stem rotation during opening and closing operations of a translatable gate valve. The magnitude of the stem rotation, and the relative difference between the stem rotation on opening and closing provides valuable data on the valve internals in a non-intrusive manner.

US Patent:

56964897, Dec 9, 1997

Filed:

Jan 11, 1996

Appl. No.:

8/584871

Inventors:

Howard D. Haynes - Knoxville TN
Curtis W. Ayers - Kingston TN

Assignee:

Lockheed Martin Energy Systems, Inc. - Oak Ridge TN

International Classification:

G08B 1316

US Classification:

340541

Abstract:

A wireless boundary monitor system used to monitor the integrity of a boundary surrounding an area uses at least two housings having at least one transmitting means for emitting ultrasonic pressure waves to a medium. Each of the housings has a plurality of receiving means for sensing the pressure waves in the medium. The transmitting means and the receiving means of each housing are aimable and communicably linked. At least one of the housings is equipped with a local alarm means for emitting a first alarm indication whereby, when the pressure waves propagating from a transmitting means to a receiving means are sufficiently blocked by an object a local alarm means or a remote alarm means or a combination thereof emit respective alarm indications. The system may be reset either manually or automatically. This wireless boundary monitor system has useful applications in both indoor and outdoor environments.

US Patent:

51935686, Mar 16, 1993

Filed:

Jun 20, 1991

Appl. No.:

7/718453

Inventors:

David M. Eissenberg - Oak Ridge TN
Howard D. Haynes - Knoxville TN
Donald A. Casada - Knoxville TN

Assignee:

Martin Marietta Energy Systems, Inc. - Oak Ridge TN

International Classification:

F16K 3700

US Classification:

137 1

Abstract:

One or more electrical coils are carefully located on the outside of a valve body. An alternating current passing through the coil(s) results in an alternating electromagnetic field being transmitted into the valve body and valve internals. The electromagnetic field varies in intensity and polarity in the valve. As the position of a valve internal part is changed, the electromagnetic field throughout the valve body and its internals is altered. A passive receiver coil carefully located on the outside of the valve body detects the intensity of the electromagnetic field at that location as an induced electrical voltage in the coil. With the change in position of the valve internal part, there is a corresponding change in the induced voltage as a result of the alteration in the alternating electromagnetic field at that location. Changes in the voltage provide an indication of the position and motion of valve internals.
