Jack L Farrar

US Patent:

42864011, Sep 1, 1981

Filed:

Apr 23, 1979

Appl. No.:

6/032170

Inventors:

Frank A. Pachmayr - Los Angeles CA
Jack R. Farrar - Whittier CA

Assignee:

Pachmayr Gun Works, Inc. - Los Angeles CA

International Classification:

F41C 2300

US Classification:

42 71P

Abstract:

A pistol grip preferably including a cushioning part having a rear portion extending across the back of a pistol handle and having side portions projecting forwardly from said rear portion at opposite sides of the handle, with the part desirably including a body of elastomeric material containing a reinforcing structure stiffer than the elastomeric material and of generally U-shaped horizontal sectional configuration. The cushioning part may be retained on the pistol handle by a fastener or fasteners extending forwardly through apertures in the back of the cushioning part and connectable to the pistol handle. The grip desirably includes a transversely extending cushioning strap preferably receivable in front of the pistol handle and formed at least in part of elastomeric material and having at least one and desirably two edge portions carrying lugs projecting inwardly toward the pistol handle into interfitting engagement with shoulders on the pistol handle to retain the lugs and attached edges of the strap against detaching movement relative to the handle. The transverse cushioning strap may be retained by reception of an edge portion thereof laterally between a side cushioning panel and the pistol handle, with that cushioning panel desirably being one of the side portions of a U-shaped cushioning part which extends across the back and along the opposite sides of the handle.

US Patent:

42428246, Jan 6, 1981

Filed:

Jan 3, 1979

Appl. No.:

6/000764

Inventors:

Frank A. Pachmayr - Los Angeles CA
Jack R. Farrar - Whittier CA

Assignee:

Pachmayr Gun Works, Inc. - Los Angeles CA

International Classification:

F41C 2300

US Classification:

47 71P

Abstract:

A pistol grip including a grip body of elastomeric material to be connected to the frame of a pistol and containing a recess within which a terminal portion of the frame extends downwardly, with the elastomeric material containing a cushioning recess which is located behind the first mentioned recess and gives to the grip body greater compressability in a front to rear direction to increase its absorption of recoil force upon firing of the gun.

US Patent:

41320247, Jan 2, 1979

Filed:

Oct 3, 1977

Appl. No.:

5/838805

Inventors:

Frank A. Pachmayr - Los Angeles CA
Jack R. Farrar - Whittier CA

Assignee:

Packmayr Gun Works, Inc. - Los Angeles CA

International Classification:

F41C 2300

US Classification:

42 71P

Abstract:

A piston grip including a body formed at least partially from elastomeric material and having two side portions to be received at opposite sides of a revolver handle, and a cross strap portion connected permanently to the side portions at rear edges thereof to extend across the back of the pistol handle. The side portions may have flanges projecting inwardly from their forward edges to be received in front of the piston handle. Relatively stiff reinforcing elements are provided in the side portions of the body, and flexible reinforcing fabric or other material is provided in the cross strap portion.

US Patent:

D2712296, Nov 1, 1983

Filed:

Sep 4, 1981

Appl. No.:

6/299409

Inventors:

Frank A. Pachmayr - Los Angeles CA
Jack R. Farrar - Whittier CA

Assignee:

Pachmayr Gun Works, Inc. - Los Angeles CA

International Classification:

D2201

US Classification:

D22 1

US Patent:

40430669, Aug 23, 1977

Filed:

Jun 7, 1976

Appl. No.:

5/693424

Inventors:

Frank A. Pachmayr - Los Angeles CA
Jack R. Farrar - Whittier CA

Assignee:

Pachmayr Gun Works, Inc. - Los Angeles CA

International Classification:

F41C 2300

US Classification:

42 71P

Abstract:

A pistol grip including two side panels to be received at opposite sides of the handle of a pistol, and cross straps to extend between the two side panels at the front and back of the handle, with all of these sections including elastomeric material having outer gripping surfaces to be contacted by the hand of a user, and with the cross straps having connector portions which extend to locations at the inner sides of the side panels and which have projections extending laterally outwardly to positions opposite coacting shoulders formed in the side panels in a relation positively locking the cross straps against detachment from the side panels.

US Patent:

41481496, Apr 10, 1979

Filed:

Jan 25, 1978

Appl. No.:

5/872329

Inventors:

Frank A. Pachmayr - Los Angeles CA
Jack R. Farrar - Whittier CA

Assignee:

Pachmayr Gun Works, Inc. - Los Angeles CA

International Classification:

F41C 2300

US Classification:

42 71P

Abstract:

A cushioned gun grip to be applied to a pistol or other gun of a type having a grip mounting projection extending downwardly and rearwardly from the frame of the gun, with the grip containing a recess dimensioned to receive the projection, and with the grip being retainable on the frame by a fastener extending through the grip and connecting to the projection. The grip includes an elastomeric body extending about the recess and projection, and a reinforcing structure stiffer than and embedded within the elastomeric material and having portions received at opposite sides of the recess and projection and having a portion at the lower end of the reinforcing structure against which a fastener can exert upward clamping force to attach the grip to the frame.

US Patent:

43971091, Aug 9, 1983

Filed:

Feb 4, 1981

Appl. No.:

6/231382

Inventors:

Frank A. Pachmayr - Los Angeles CA
Jack R. Farrar - Los Angeles CA

Assignee:

Pachmayr Gun Works, Inc. - Los Angeles CA

International Classification:

F41C 2502

US Classification:

42 50

Abstract:

A cushioning pad adapted to be connected to the lower end of a gun cartridge clip and including a body of elastomeric material to be engaged by a user's hand in pressing the clip upwardly into the handle of the gun, and a reinforcing plate embedded within the elastomeric material and through which screws extend upwardly for connection into the bottom wall of the clip body, with the screws having heads applying upward force to the reinforcing element in a manner securing the pad on the clip. If the clip is of a type having a horizontally slidably removable bottom wall, the pad may be secured to that wall and contain a passage through which a tool is insertable upwardly to a position for engaging and releasing a latch element normally holding the bottom wall against detaching movement.

US Patent:

60733810, Jun 13, 2000

Filed:

Jul 17, 1998

Appl. No.:

9/118465

Inventors:

Frank W. Farrar - Los Alamitos CA
Jack R. Farrar - Whittier CA

International Classification:

F41C 2310

US Classification:

42 7102

Abstract:

A thin walled finger groove adapter for a handgun comprising a very thin ductile metal reinforcing plate encapsulated with thin front and back layers of elastomeric material. At least one finger groove projection is provided on the front surface of the adapter in registry with a hole through the reinforcing plate so that the projection is integral with both the front and back layers of encapsulating material. The finger groove adapter is substantially no greater than 0. 040 inches thick with the metal plate being no more than about 0. 015, and preferably about 0. 010, inches thick. It is well suited for handgun users who have small hands. The finger groove adapter is molded in a flat condition and may be trimmed in the flat configuration to a variety of final shapes so as to accommodate mounting to a variety of different handgun handles. The finger groove adapter is sold in the flat or only slightly bent configuration, and is deformed into the appropriate shape for mounting to the handgun by the user.
