Jeronimo Olea

US Patent:

20210402620, Dec 30, 2021

Filed:

Jun 25, 2020

Appl. No.:

16/912379

Inventors:

- Palm Springs FL, US
Jeronimo Olea - Boca Raton FL, US

International Classification:

B25J 15/06
A45D 33/00
B65B 1/24

Abstract:

In the manufacture of certain cosmetics packaging, small metal pans are used to carry the cosmetic material, and these are incorporated in cosmetics carriers. The cosmetic material is initially in a powder form that is compressed into the pan prior to the pan being assembled into a carrier A multi-pan insertion tool includes a control plate and one or more interface plates that can, in turn, be attached to the control plate. Each interface plate corresponds to a different pan configuration. The interface plate includes a plurality of protrusion sites that each correspond to a single pan. An air passage from each protrusion site passes through the tool to the valve on the control plate that is controlled by an operator (either open or closed). A vacuum hose is attached to the valve to create the necessary vacuum/suction. The operator can then use the tool to pick up multiple pans at once, using suction, and then deposit the pans into a press for powder loading and then compression of the powder.
