John M Anemaet

US Patent:

49277090, May 22, 1990

Filed:

Sep 16, 1988

Appl. No.:

7/245760

Inventors:

Tim Parker - Shrewsbury MA
Robert M. Edwards - Milford MA
Frank A. Magnotta - Framingham MA
Jean-Paul Laprade - Woonsocket RI
Donald R. Smith - Hingham MA
Eleanor H. Sodagar - Worcester MA
John M. Anemaet - Millis MA
Dennis R. Benoit - Woonsocket RI
Earl K. Thornton - Andover MA
Richard J. Galante - Milford MA

Assignee:

Dennison Manufacturing Company - Framingham MA

International Classification:

C09J 702

US Classification:

428352

Abstract:

An improved release system for heat transferable laminates wherein a transferable substrate which contains a design layer is transferred from a carrier web onto an article such as a plastic bottle or container upon application of heat and pressure. The carrier web includes a nonwax polyethylene layer. The improved release system includes a polyethylene layer portion of the carrier web in contact with and adhered to a nonwax transfer layer portion of the transferable substrate. The transferable substrate including the ink design layer transfers to the article upon application of heat to the carrier while the article contacts the laminate. The transferred substrate with design layers on the article is clear and exhibits improved scuff and abrasion resistance.

US Patent:

48702510, Sep 26, 1989

Filed:

Nov 1, 1985

Appl. No.:

6/793875

Inventors:

John M. Anemaet - Millis MA

Assignee:

Dennison Manufacturing Company - Framingham MA

International Classification:

H05B 100
H05B 306
B02C 1108
B30B 1534

US Classification:

219243

Abstract:

A heat transfer pad molded over elongated projections, such as bolts, to conduct heat to the pad interior, and securely maintain the pad on a support. A heater assembly slideably retains the pad and support, and includes replaceable heating elements, which are insulated from a mounting assembly.

US Patent:

45554366, Nov 26, 1985

Filed:

May 3, 1984

Appl. No.:

6/606747

Inventors:

Friedrich H. H. Geurtsen - Holliston MA
John M. Anemaet - Millis MA
Donald R. Smith - Hingham MA
Mary G. Boyd - Framingham MA

Assignee:

Dennison Manufacturing Co. - Framingham MA

International Classification:

B32B 706
C09J 702
C09J 704

US Classification:

428200

Abstract:

An improved release formulation for use in a heat transferable laminate wherein an ink design image is transferred from a carrier support to an article by application of heat to the carrier support. On transfer the release splits from the carrier and forms a protective coating over the transfered design. The improved release is coated onto the carrier as a solvent based-wax release. The release coating is then dried to evaporate the solvent contained therein. The improved release has the property that its constituents remain in solution down to temperatures approaching ambient temperature. Upon transfer, the release forms a protective coat which may be subjected to hot water. The improved release contains a montan wax, a rosin ester or hydrocarbon resin, a solvent, and ethylene-vinyl acetate copolymer having a low vinyl acetate content.

US Patent:

45114250, Apr 16, 1985

Filed:

Jun 13, 1983

Appl. No.:

6/503486

Inventors:

Mary G. Boyd - Framingham MA
Donald R. Smith - Hingham MA
Peter F. Imondi - Providence RI
Norman A. Hiatt - Framingham MA
Fritz E. Bauer - Shrewsbury MA
John M. Anemaet - Millis MA
Alfred K. MacKenzie - Wayland MA

Assignee:

Dennison Manufacturing Company - Framingham MA

International Classification:

B32B 3100
B30B 502
B44C 300

US Classification:

156493

Abstract:

Apparatus for heat transfer labelling of articles using a resilient pad maintained at elevated temperatures. Decorative laminates affixed to a support member such as a web are fed to a heated platen. A resilient pad consisting of a silicone elastomer is pressed against the laminate at the heated platen, whereby the laminate adheres to the pad when it retracts from the platen. The heated pad is then pressed against an article to be labelled, to which the transfer substrate adheres in preference to the pad surface. The resilient pad is typically heated to a temperature above ambient temperature but lower than that of the heated platen. The pad is heated by repetitive contact with the platen, and additionally by an independent heater. The pad may include one or more interior heating elements, or an exterior radiant heater located adjacent the pad during periods between label transfers. This apparatus is well suited to the labelling of articles of a wide variety of sizes, shapes, and materials.

US Patent:

49353004, Jun 19, 1990

Filed:

Apr 13, 1988

Appl. No.:

7/181090

Inventors:

Tim Parker - Shrewsbury MA
Frank A. Magnotta - Framingham MA
Jean-Paul Laprade - Woonsocket RI
Donald R. Smith - Hingham MA
John M. Anemaet - Millis MA
Dennis R. Benoit - Woonsocket RI
Earl K. Thornton - Andover MA

Assignee:

Dennison Manufacturing Company - Framingham MA

International Classification:

C09J 702

US Classification:

428352

Abstract:

An improved release system for heat transferable laminates wherein a transferable substrate which contains a design layer is transferred from a carrier web onto an article such as a plastic bottle or container upon application of heat and pressure. The carrier web includes a nonwax polyethylene layer. The improved release system includes a polyethylene layer portion of the carrier web in contact with and adhered to a nonwax transfer layer portion of the transferable substrate. The transferable substrate including the ink design layer transfers to the article upon application of heat to the carrier while the article contacts the laminate. The transferred substrate on the article is clear and exhibits improved scuff and abrasion resistance. The nonwax transfer layer portion of the transferable substrate advantageously contains an oil which becomes activated upon application of heat to promote release of the transferable substrate from the carrier web to the article.
