John S Maclean

US Patent:

42238439, Sep 23, 1980

Filed:

Mar 16, 1978

Appl. No.:

5/887289

Inventors:

Randlow Smith - Houston TX
John P. MacLean - Stafford TX
Dale Williams - Houston TX
Rich W. Barkley - Houston TX
Henry B. Jones - Houston TX

Assignee:

Texaco Inc. - White Plains NY

International Classification:

B01J 808
B01J 2120

US Classification:

239558

Abstract:

An air distribution apparatus for delivering an oxygen-carrying gas such as air to a zone of spent catalyst in a regenerator for the purpose of combusting air with the spent catalyst in order to rejuvenate the catalyst. A header support assembly is adapted for mounting in a regenerator which receives the spent catalyst. A hollow header ring is mounted onto the header support assembly and includes a plurality of openings each having a nozzle mounted therein. Air is supplied to the header support assembly and thus to the hollow header ring at a pressure sufficiently high to effect a maximum desired pressure differential between header pressure and pressure in the zone of spent catalyst to cause maximum uniform air distribution. The nozzles mounted in the openings in the header ring decrease air velocity between nozzle inlet and nozzle outlet in order to provide for maximum uniform air distribution without destruction of the catalyst.

US Patent:

43801056, Apr 19, 1983

Filed:

Jul 7, 1980

Appl. No.:

6/166714

Inventors:

John P. MacLean - Stafford TX
J. Edward Cantwell - Houston TX
John D. Brown - The Woodlands TX
Harold D. Hoy - Bridge City TX

Assignee:

Texaco Inc. - White Plains NY

International Classification:

B23P 1500
B01D 4512

US Classification:

29157R

Abstract:

A few methods for shaping and assembling a highly efficient cyclone separator for the removal of entrained solids from gases comprises basically, among other steps, the novel steps of: (1) attaching a solids-free-gas outlet (74) having an area (O) to the upper portion of the separator housing shaped for receiving solids-free-gas at a velocity in the range of 52 feet per second to 200 feet per second, (2) forming the solids-free-gas outlet area (O) proportional to the separator inlet area (I) in the range of substantially O/I=0. 4/1 to 1. 0/1. 0, and (3) forming the distance (L) from the gas outlet (74) to the solids outlet (70) proportional to the diameter (D) of the cyclone separator cylindrical portion (56) in an amount of L/D=4. 49-1. 09 (O/I) for providing maximum efficiency with minimum erosion of both the cyclone separator internal housing wall surface and of the separated solids. L/D is about 4.

US Patent:

40860647, Apr 25, 1978

Filed:

Dec 6, 1976

Appl. No.:

5/748090

Inventors:

John P. MacLean - Stafford TX
John C. Strickland - Houston TX

Assignee:

Texaco Inc. - New York NY

International Classification:

B01J 824

US Classification:

23288G

Abstract:

In a fluidized catalytic cracking unit a riser discharge head for discharging catalyst and hydrocarbon vapor from a riser conduit substantially vertically downward into a vertical reaction vessel such that erosion of the discharge head and the reaction walls is avoided.

US Patent:

40351530, Jul 12, 1977

Filed:

May 7, 1976

Appl. No.:

5/684509

Inventors:

Dorrance P. Bunn - Houston TX
Dale Williams - Houston TX
Henry B. Jones - Houston TX
John P. MacLean - Stafford TX

Assignee:

Texaco Inc. - New York NY

International Classification:

B01J 808
B01J 3712

US Classification:

23288B

Abstract:

Apparatus for regeneration of spent, coke contaminated fluidized cracking catalyst by burning coke therefrom with a molecular oxygen containing regeneration gas in a fluidized dense phase bed, and for burning substantially all carbon monoxide to carbon dioxide. Means are provided for transferring heat from the top of said regeneration apparatus to the bottom, employing catalyst as the transfer medium. Additionally, means are provided for maintaining a homogeneous fluidized dense phase bed of catalyst undergoing regeneration. Also, conical standpipe means is provided for deaerating regenerated catalyst.

US Patent:

43370683, Jun 29, 1982

Filed:

Oct 20, 1980

Appl. No.:

6/198416

Inventors:

John P. MacLean - Stafford TX
J. Edward Cantwell - Houston TX
John D. Brown - The Woodlands TX
Harold D. Hoy - Bridge City TX

Assignee:

Texaco Inc. - White Plains NY

International Classification:

B01D 4516

US Classification:

55 1

Abstract:

A method for the removal of entrained solids from gases in a cyclone separator having a dipleg attached to the bottom thereof comprises the basic steps of, (1) injecting the gases with the entrained solids in an inlet (54) of cyclone separator in the range of substantially 52 feet per second (16 m/s) to 80 feet per second (24 m/s), (2) spinning the injected gases with the entrained solids around and down the cyclone separator to the inlet (70) of the dipleg (34) by a vertical distance (L) below the gas outlet (74) proportional to the diameter (D) of the top of the separator by an amount of L/D=4. 49-1. 09 (O/I) or about 4, and (3) ejecting the solids-free-gases through a gas outlet (74) in the range of substantially 52 feet per second (16 m/s) to 200 feet per second (61 m/s) having an area (O) in proportion to the area (I) of the separator inlet (54) in the range of substantially O/I=0. 4/1 to 1/1, for providing a maximum efficiency with minimum erosion of both the cyclone separator internal wall surface and of the separated solids.

US Patent:

44664796, Aug 21, 1984

Filed:

Aug 19, 1982

Appl. No.:

6/409390

Inventors:

John P. MacLean - Houston TX

Assignee:

Texaco Inc. - White Plains NY

International Classification:

F28C 316

US Classification:

165 1

Abstract:

A method for transferring heat between two fluids comprises (1) flowing the first fluid in an upright diamond shaped tube, and (2) flowing the second fluid therearound the tube over upper and lower surfaces of the diamond shaped tube formed at an angle to the horizon that is greater than the angle of repose of the second fluid therearound the tube for preventing accumulation of second fluid sediment on top and stagnant gases on the bottom of the tube. A novel heat exchanger tube is also disclosed.

US Patent:

42206235, Sep 2, 1980

Filed:

Mar 29, 1978

Appl. No.:

5/891414

Inventors:

Frederick C. Jahnke - Houston TX
John P. MacLean - Stafford TX
Dale Williams - Houston TX
John D. Brown - The Woodlands TX

Assignee:

Texaco Inc. - White Plains NY

International Classification:

B01J 826
C10G 1318
C10G 3514

US Classification:

422144

Abstract:

A fluidized catalytic cracking unit wherein cyclone diplegs extend from the reactor vessel into the stripping vessel, for reducing the overall height of the unit. Valve means are provided at the lower end of the diplegs to prevent blow by of gas through the diplegs. The diplegs pass through the vent lines.

US Patent:

41382196, Feb 6, 1979

Filed:

Jul 5, 1977

Appl. No.:

5/813139

Inventors:

James H. Colvert - Houston TX
John P. MacLean - Stafford TX
Dale Williams - Houston TX
Henry B. Jones - Houston TX

Assignee:

Texaco Inc. - New York NY

International Classification:

B01J 828

US Classification:

422144

Abstract:

Apparatus for the regeneration of fluidized solid catalyst including a regeneration chamber adapted to hold a fluidized solids bed, oxygen containing gas source communicating with the chamber, a tangential inlet communicating with the regeneration chamber to impart a swirling motion to spent catalyst entering the regeneration chamber and a free standing drawoff conduit disposed within the regeneration chamber, the drawoff conduit having an upper, open end in communication with the solids bed, the open end being formed by an obliquely truncated, outwardly flared portion of the conduit, the high portion of said truncated conduit lying closest the spent catalyst inlet.
