Jonathan D Stewart

US Patent:

6567526, May 20, 2003

Filed:

Oct 13, 2000

Appl. No.:

09/687931

Inventors:

Mead C. Killion - Elk Grove Village IL
Jonathan Stewart - Bloomingdale IL
Don Wilson - Barrington IL
Matthew J. Roberts - Palatine IL
Steve Iseberg - Rolling Meadows IL
Timothy S. Monroe - Schaumburg IL

Assignee:

Etymotic Research, Inc. - Elk Grove Village IL

International Classification:

H04R 2500

US Classification:

381313, 381356, 381328

Abstract:

A microphone capsule for an in-the-ear hearing aid is disclosed. The capsule can include a top plate having first and second spaced openings defining front and rear sound inlets, and a directional microphone cartridge enclosing a diaphragm. The diaphragm is oriented generally perpendicular to the top plate and divides the directional microphone cartridge housing into a front chamber and a rear chamber. A front sound passage communicates between the front sound inlet and the front chamber, and a rear sound passage communicates between the rear sound inlet and the rear chamber. Front and rear acoustic damping resistors are associated with the front and rear sound passages. The acoustic resistor pair provides a selected time delay, such as about 4 microseconds, between the front and rear sound passages. The use of two acoustic resistors instead of one levels the frequency response, compared to the frequency response provided by a rear acoustic damping resistor alone.

US Patent:

6831987, Dec 14, 2004

Filed:

May 19, 2003

Appl. No.:

10/441544

Inventors:

Mead C. Killion - Elk Grove Village IL
Jonathan Stewart - Bloomingdale IL
Don Wilson - Barrington IL
Matthew J. Roberts - Palatine IL
Steve Iseberg - Rolling Meadows IL
Timothy S. Monroe - Schaumburg IL

Assignee:

Etymotic Research, Inc. - Elk Grove Village IL

International Classification:

H04R 2500

US Classification:

381313, 381356, 381357

Abstract:

A microphone capsule for an in-the-ear hearing aid is disclosed. The capsule can include a top plate having first and second spaced openings defining front and rear sound inlets, and a directional microphone cartridge enclosing a diaphragm. The diaphragm is oriented generally perpendicular to the top plate and divides the directional microphone cartridge housing into a front chamber and a rear chamber. A front sound passage communicates between the front sound inlet and the front chamber, and a rear sound passage communicates between the rear sound inlet and the rear chamber. Front and rear acoustic damping resistors are associated with the front and rear sound passages. The acoustic resistor pair provides a selected time delay, such as about 4 microseconds, between the front and rear sound passages. The use of two acoustic resistors instead of one levels the frequency response, compared to the frequency response provided by a rear acoustic damping resistor alone.

US Patent:

7551940, Jun 23, 2009

Filed:

Jan 8, 2004

Appl. No.:

10/755106

Inventors:

Mary Paulson - Elk Grove Village IL, US
Jonathan K. Stewart - Bloomingdale IL, US
Andrew J. Haapapuro - Arlington Heights IL, US
Viorel Drambarean - Skokie IL, US
Robert B. Schulein - Schaumburg IL, US
Mead C. Killion - Elk Grove Village IL, US

Assignee:

Etymotic Research, Inc. - Elk Grove Village IL

International Classification:

H04M 1/00
H04R 25/00

US Classification:

4555501, 4555691, 4555692, 4555751, 4555561, 381370, 381375, 381380, 379430

Abstract:

A two-way voice communication device which provides a high-level of acoustic noise reduction is disclosed. A resilient ear tip provides acoustic isolation and secures the earphone within the ear canal of the user. The ability to rotate the earphone within the ear canal allows the user to easily position an attached microphone. The audio signals may be conveyed by an included radio frequency receiver and radio frequency transmitter, or the earphone may be connected to an electrical audio device using a multi-conductor cable. Audio signals may be conveyed to one or both ears of a user. A switch to mute the audio signal from the microphone, or for supporting a push-to-talk mode of operation, may be included in the earphone housing, or on the cable.

US Patent:

8184839, May 22, 2012

Filed:

Jan 7, 2005

Appl. No.:

11/031915

Inventors:

Gail Gudmundsen - Elk Grove Village IL, US
Mead C. Killion - Elk Grove Village IL, US
Viorel Drambarean - Skokie IL, US
Jonathan K. Stewart - Bloomingdale IL, US

Assignee:

Etymotic Research, Inc. - Elk Grove Village IL

International Classification:

H04R 25/00

US Classification:

381323, 381322, 381328

Abstract:

A hearing-aid device comprising a housing and circuitry module, wherein the circuitry module comprises a battery, a microphone, and a receiver, and the circuit module is inserted in the hearing aid housing. The hearing aid device further comprises a retractable battery sleeve, wherein a battery slot is exposed when the battery sleeve is retracted, and a battery can be inserted into the battery slot from either side of the battery slot with either polarity. The hearing aid housing may comprise an ear-tip, wherein a microphone is mounted in the hearing aid housing near the ear-tip and the microphone receives sounds through at least one sound inlet located on a side surface of the hearing aid housing. The ear-tip additionally comprises three flanges decreasing in size toward the flange closest to the ear canal, and the hearing aid can be inserted into the ear canal in any orientation.

US Patent:

8625827, Jan 7, 2014

Filed:

Apr 26, 2012

Appl. No.:

13/456963

Inventors:

Gail Gudmundsen - Elk Grove Village IL, US
Viorel Drambarean - Elk Grove Village IL, US
Mead C. Killion - Elk Grove Village IL, US
Jonathan K. Stewart - Bloomingdale IL, US

Assignee:

Etymotic Research, Inc. - Elk Grove Village IL

International Classification:

H04R 25/00

US Classification:

381323, 381322, 381328

Abstract:

A hearing-aid device comprising a housing and circuitry module, wherein the circuitry module comprises a battery, a microphone, and a receiver, and the circuit module is inserted in the hearing aid housing. The hearing aid device further comprises a retractable battery sleeve, wherein a battery slot is exposed when the battery sleeve is retracted, and a battery can be inserted into the battery slot from either side of the battery slot with either polarity. The hearing aid housing may comprise an ear-tip, wherein a microphone is mounted in the hearing aid housing near the ear-tip and the microphone receives sounds through at least one sound inlet located on a side surface of the hearing aid housing. The ear-tip additionally comprises three flanges decreasing in size toward the flange closest to the ear canal, and the hearing aid can be inserted into the ear canal in any orientation.

US Patent:

20070098202, May 3, 2007

Filed:

Oct 26, 2006

Appl. No.:

11/553460

Inventors:

Steven Viranyi - Palatine IL, US
Edgar Villchur - Woodstock NY, US
Donald Wilson - Barrington IL, US
Mead Killion - Elk Grove Village IL, US
Jonathan Stewart - Bloomingdale IL, US

International Classification:

H04R 25/00

US Classification:

381380000, 381370000

Abstract:

Embodiments of the present invention relate to an earphone that allows for individual adjustment of different audio levels produced out of a first and second speaker to compensate for hearing impairment in one or both ears. The earphone may include a jack plug that is configured for insertion into an audio source that has a first volume control for setting the audio volume level produced by the first speaker. The earphone may also include a second volume control having an inlet and an outlet the inlet being operably connected to the jack plug. The second volume control may be configured to adjust the audio volume level produced by the second speaker. The maximum audio volume level of the second volume control may be approximately the same as the audio volume level set by the first volume control. The minimum audio volume of the second volume control may be inaudible.

US Patent:

51139677, May 19, 1992

Filed:

May 7, 1990

Appl. No.:

7/519855

Inventors:

Mead C. Killion - Elk Grove Village IL
Jonathan K. Stewart - Bensenville IL
Robert Falco - Indianapolis IN
Elliott H. Berger - Indianapolis IN

Assignee:

Etymotic Research, Inc. - Elk Grove Village IL

International Classification:

A61B 702

US Classification:

181132

Abstract:

An earplug uses damping to render unimportant a Helmholtz resonance between the acoustic mass intrinsic to a sound channel thereof and the compliance of air in the earcanal, in combination with a readily manufacturable external structure coupled to the sound channel to increase response characteristics at higher frequencies in a predictable and well controlled manner in order to provide a highly desireable uniform frequency response.

US Patent:

58781471, Mar 2, 1999

Filed:

Dec 31, 1996

Appl. No.:

8/775139

Inventors:

Mead C. Killion - Elk Grove Village IL
Jonathan Stewart - Bloomingdale IL
Don Wilson - Barrington IL
Matthew J. Roberts - Palatine IL
Steve Iseberg - Rolling Meadows IL
Timothy S. Monroe - Schaumburg IL

Assignee:

Etymotic Research, Inc. - Elk Grove Village IL

International Classification:

H04R 2500

US Classification:

381313

Abstract:

A microphone capsule for an in-the-ear hearing aid is disclosed. The capsule can include a top plate having first and second spaced openings defining front and rear sound inlets, and a directional microphone cartridge enclosing a diaphragm. The diaphragm is oriented generally perpendicular to the top plate and divides the directional microphone cartridge housing into a front chamber and a rear chamber. A front sound passage communicates between the front sound inlet and the front chamber, and a rear sound passage communicates between the rear sound inlet and the rear chamber. Front and rear acoustic damping resistors having different resistance values are associated with the front and rear sound passages. The acoustic resistor pair provides a selected time delay, such as about 4 microseconds, between the front and rear sound passages. The use of two acoustic resistors instead of one levels the frequency response, compared to the frequency response provided by a rear acoustic damping resistor alone.
