Lee R Bandy

US Patent:

49206273, May 1, 1990

Filed:

Feb 26, 1988

Appl. No.:

7/160620

Inventors:

Robert D. Aikins - Norristown PA
Lee R. Bandy - West Chester PA
William R. Davis - Downingtown PA
Robert E. Delaney - Devon PA
Michael E. Guyer - Coatesville PA
Edward D. Lovera - Aston PA
Thomas A. Scamuffa - Parkesburg PA

Assignee:

LG Industries, Inc. - Wagontown PA

International Classification:

B23P 700

US Classification:

2940208

Abstract:

Metal carrier rolls having a mass of at least about 100 pounds for use in paper making, non-woven fabric making and other applications are balanced to within a predetermined first residual unbalance value for rotation of the roll up to a predetermined maximum service speed of at least about 100 RPM, preferably within a Balance Quality Grade G-6. 3 residual unbalance value, by fabricating a pair of substantially identical removably mountable metal journals, each being balanced to within a second residual unbalance value less than the first residual unbalance value, preferably to within a Balance Quality Grade G-2. 5 residual unbalance value, fabricating a body assembly including a hollow metal body with a pair of metal end heads each being adapted for removably mounting a journal, the body assembly being balanced to within a third residual unbalance value less than the difference between the first and twice the second residual unbalance values, and, preferably, within a Balance Quality Grade G-2. 5 residual unbalance value, and removably mounting the pair of journals to the end heads to form the roll balanced to within the first residual unbalance value.
