Lincoln M Jore

US Patent:

20060202584, Sep 14, 2006

Filed:

Feb 5, 2004

Appl. No.:

10/543752

Inventors:

Lincoln Jore - Ronan MT, US
Matthew Jore - Ronan MT, US

International Classification:

H02K 3/00
H02K 21/00
H02K 1/22

US Classification:

310179000, 310268000, 310207000

Abstract:

The present invention provides an axial rotary energy device which is arranged in a multi-phase electric current configuration. The device includes a rotor having a plurality of permanent magnet poles secured thereto and further includes a stator formed by stacking a plurality of printed circuit board working conductor layers together with a plurality of printed circuit board connecting layers. The stator having at least one working conductor layer for each phase of the electric current and at least one connecting conductor layer associated with one working conducting layer. The working conductor layer and the connecting conductor layer each having radial conductors extending from an inner diameter through-hole to an outer diameter through-hole. A plurality of via conductors are provided for electrically connecting selected ones of the radial connectors of the connecting conductor layer to selected ones of the radial connectors of the working conductor layers through the through-holes.

US Patent:

20120217831, Aug 30, 2012

Filed:

Jun 2, 2011

Appl. No.:

13/152164

Inventors:

Matthew B. Jore - Ronan MT, US
Lincoln Jore - Ronan MT, US
Michael A. Kvam - Polson MT, US
James D. Jore - Polson MT, US
David Samsel - Missoula MT, US
James David Duford - Polson MT, US
James S. Smith - Lyons CO, US

International Classification:

H02K 21/24

US Classification:

310 90, 31015632

Abstract:

Systems and methods for improved generators are described. One embodiment includes an assembly for an axial flux generator, the assembly comprising an arc-shaped rotor section that includes a rotor support configured to rotate around an axis of a generator, and an at least one rotor element for power generation that is connected to the rotor support; an arc-shaped stator section comprising a stator support and an at least one stator element for power generation connected to the stator support; wherein the rotor section and the stator section are configured to provide an axial air gap between the at least one rotor element and the at least one stator element, and wherein the at least one rotor element and the at least one stator element are positioned to be at substantially the same radial distance from the axis of the generator.

US Patent:

20140049130, Feb 20, 2014

Filed:

Jan 15, 2010

Appl. No.:

13/144642

Inventors:

Matthew B. Jore - Ronan MT, US
James David Duford - Polson MT, US
Michael Kvam - Polson MT, US
Lincoln M. Jore - Ronan MT, US
David Samsel - Missoula MT, US
James D. Jore - Polson MT, US

International Classification:

H02K 21/24

US Classification:

31015637

Abstract:

An axial rotary energy device including a segmented stator assembly having a plurality of segments arranged in an annular array. Each stator segment is constructed by stacking a plurality of PCB power conductor layers and a plurality of PCB series layers. Each layer having radial conductors extending from an inner via to an outer via. The vias electrically connect selected radial conductors of the series conductor layer and power conductor layer. Each power conductor layer includes a pair of positive and negative terminal vias for one phase of the electric current connected to selected outer vias. A daughter PCB layer electrically connects two adjacent segments together by having a first portion electrically connected to a negative terminal via located in one segment and a second portion electrically connected to a positive terminal via located in an adjacent segment together with a current conductor electrically connecting the two terminal vias together.

US Patent:

20180358664, Dec 13, 2018

Filed:

Feb 26, 2018

Appl. No.:

15/904821

Inventors:

- Valley City OH, US
Matthew M. BOSWAY - Gilbert AZ, US
Lincoln JORE - Scottsdale AZ, US

International Classification:

H01M 10/613
H01M 10/42
H01M 10/643
H01M 2/10
H01M 10/6557

Abstract:

A rechargeable battery pack having a housing, a plurality of cells located within the housing, a heat sink for dissipating heat from the plurality of cells, wherein the plurality of cells are encapsulated by the heat sink, and at least one elongated cooling channel to provide for active cooling, wherein the elongated cooling channel is within the housing and at least partially defined by the heat sink. A rechargeable battery pack having a housing, a plurality of cells located within the housing, wherein no single cell is completely surrounded by adjacent cells, a heat sink for dissipating heat from the plurality of cells, wherein the plurality of cells are encapsulated by the heat sink, and at least one elongated cooling channel to provide for active cooling, wherein the elongated cooling channel is located within the housing and is at least partially defined by the heat sink.

US Patent:

20180219445, Aug 2, 2018

Filed:

Sep 11, 2017

Appl. No.:

15/700860

Inventors:

- Louisville CO, US
James David DUFORD - Polson MT, US
Michael KVAM - Polson MT, US
Lincoln M. JORE - Ronan MT, US
David SAMSEL - Missoula MT, US
James D. JORE - Polson MT, US

Assignee:

Boulder Wind Power, Inc. - Louisville CO

International Classification:

H02K 3/26
H02K 3/47
H02K 21/24
H02K 1/12

Abstract:

An axial rotary energy device including a segmented stator assembly having a plurality of segments arranged in an annular array. Each stator segment is constructed by stacking a plurality of PCB power conductor layers and a plurality of PCB series layers. Each layer having radial conductors extending from an inner via to an outer via. The vias electrically connect selected radial conductors of the series conductor layer and power conductor layer. Each power conductor layer includes a pair of positive and negative terminal vias for one phase of the electric current connected to selected outer vias. A daughter PCB layer electrically connects two adjacent segments together by having a first portion electrically connected to a negative terminal via located in one segment and a second portion electrically connected to a positive terminal via located in an adjacent segment together with a current conductor electrically connecting the two terminal vias together.

US Patent:

20140175922, Jun 26, 2014

Filed:

Feb 28, 2014

Appl. No.:

14/193012

Inventors:

- Louisville CO, US
James David Duford - Polson MT, US
Michael Kvam - Polson MT, US
Lincoln M. Jore - Ronan MT, US
David Samsel - Missoula MT, US
James D. Jore - Polson MT, US

Assignee:

Boulder Wind Power, Inc. - Louisville CO

International Classification:

H02K 3/26

US Classification:

310 71

Abstract:

An axial rotary energy device including a segmented stator assembly having a plurality of segments arranged in an annular array. Each stator segment is constructed by stacking a plurality of PCB power conductor layers and a plurality of PCB series layers. Each layer having radial conductors extending from an inner via to an outer via. The vias electrically connect selected radial conductors of the series conductor layer and power conductor layer. Each power conductor layer includes a pair of positive and negative terminal vias for one phase of the electric current connected to selected outer vias. A daughter PCB layer electrically connects two adjacent segments together by having a first portion electrically connected to a negative terminal via located in one segment and a second portion electrically connected to a positive terminal via located in an adjacent segment together with a current conductor electrically connecting the two terminal vias together.
