Lynn J Russell

US Patent:

60707372, Jun 6, 2000

Filed:

Dec 30, 1997

Appl. No.:

9/000721

Inventors:

Lynn A. Russell - Scappoose OR
Warren A. Strout - Whitter CA

Assignee:

Western Wire Works, Inc. - Portland OR

International Classification:

B07B 134
B07B 138
B07B 149

US Classification:

209326

Abstract:

The method and system of the present invention provides for fast, convenient and low cost installation and removal from a particulate screening assembly of an apparatus for protecting the underlying structural members of the screening assembly from the adverse affects caused by the flow therethrough of particulate material. The subject system includes a wear protector system designed for direct attachment to and removal from the structural members which support the screening assembly. This direct attachment and removal operation occurs without the need to detach or disassemble the support structure from the screening assembly. Thus, the wear protector system can be readily removed and replaced without expending substantial downtime in completing system maintenance.

US Patent:

50492624, Sep 17, 1991

Filed:

Nov 20, 1989

Appl. No.:

7/439969

Inventors:

Zanley F. Galton - Portland OR
Lynn A. Russell - Scappoose OR
L. Allen Dorn - Washougal WA

International Classification:

B07B 146
B07B 118
F16B 2114

US Classification:

209399

Abstract:

A system for screening particulate material includes replaceable screening modules mounted to a rigid frame by lock pins. The lock pins are fixed into mounting holes in the frame and interlockingly and removably engage recesses in the sidewalls of the screening modules so that the lock pins remain fixed to the frame while allowing the modules to be removed and replaced as required due to wear or to change sieve size. A split lock pin is provided for removably connecting the module to the frame along an outboard edge of the frame while maximizing screening area. An improved elongate frame member is arranged to avoid abrasive wear of the frame.
