Peter F Reile

US Patent:

6479741, Nov 12, 2002

Filed:

May 17, 2001

Appl. No.:

09/858892

Inventors:

Kenneth P. Morton - East Aurora NY
Kenneth G. Parker - Williamsville NY
Peter F. Reile - South Wales NY
Maarten Van Huystee - East Aurora NY

Assignee:

Mattel, Inc. - El Segundo CA

International Classification:

G10D 1500

US Classification:

84644, 84670, 84 2, 84171, 446408

Abstract:

A musical device includes a body and at least one actuator mechanism. In one embodiment, the musical device can generate an audio output in response to activation by a user of the actuator mechanism. In one embodiment, the musical device body includes multiple parts that can be moved relative to each other. The parts enable the musical device to resemble one or more musical instruments.

US Patent:

6771034, Aug 3, 2004

Filed:

Feb 20, 2002

Appl. No.:

10/081934

Inventors:

Peter Reile - South Wales NY
Brian L. Bienz - West Seneca NY

Assignee:

Mattel, Inc. - El Segundo CA

International Classification:

H02P 500

US Classification:

318139, 318256, 318282, 388825, 388829, 446457, 446460, 446465, 446436, 180 651

Abstract:

A childrens ride-on vehicle having an electronic speed controller adapted to regulate at least one of the timing and rate of application of a selected rotational input. The vehicle includes a body with a seat, a steering mechanism positioned for operation by a child to steer at least one of the vehicles wheels, and a drive assembly with an actuator positioned for actuation by a child sitting on the seat to cause the driven rotation of at least one of the vehicles wheels by a battery-powered motor assembly. In some embodiments, the drive assembly includes one or more user input devices that enable a child sitting on the seat to select at least one of the relative speed and direction of the vehicle. The drive assembly also includes an electronic speed controller that controls electronically the transmission of a selected rotational input to the vehicles driven wheel assembly.

US Patent:

60316624, Feb 29, 2000

Filed:

Feb 6, 1998

Appl. No.:

9/019640

Inventors:

Jeffrey J. Miller - Orchard Park NY
Peter F. Reile - South Wales NY
Stephen D. Fantone - Lynnfield MA

Assignee:

Fisher - Price, Inc. - East Aurora NY

International Classification:

G02B 2302
G02B 2722

US Classification:

359407

Abstract:

A dual purpose optical device that is convertible between binocular and stereoscope modes of operation while using a common eyepiece arrangement for both. The device includes a housing containing a pair of optic supports mounted side-by-side for lateral movement towards and away from one another. Each support preferably carries three lenses. Two lenses on each support serve as the eyepiece and are aligned in a common plane with an eyepiece opening through the housing and a rotatable mirror assembly. The assembly pivots substantially ninety degrees from opposing forty-five degree angle positions with respect to the plane through the eyepiece opening and the eye and field lenses so as to fold the lines of sight either up or down within the housing. A circular photo transparency reel is received horizontally in a slot provided on an upper side of the housing. Each optic support is provided with three fixed mirrors which fold the lines of sight directed downward by the rotating mirror through an objective lens located at an opposite end of the housing.
