Peter J Wong

US Patent:

20170071608, Mar 16, 2017

Filed:

Nov 28, 2016

Appl. No.:

15/362320

Inventors:

- Southborough MA, US
Jay A. Casey - Memphis TN, US
Peter Y. Wong - Arlington TN, US
Jesse Conrad - Cordova TN, US

International Classification:

A61B 17/16
B23B 31/20
B23B 31/107

Abstract:

A surgical device comprising: a handle assembly; a locking collar; and a set of replaceable bits that load along an axis into the handle assembly; wherein the locking collar is fully removable from the handle assembly, the locking collar loads axially to a first position, and the locking collar rotates between the first position and a second position; wherein, in the first position, the locking collar is free to be axially removed from the handle assembly and the replaceable bits are free to be loaded or unloaded from the handle assembly; wherein, in the second position, the locking collar is prevented from axial movement relative to the handle assembly and the replaceable bits are prevented from being received within, or removed from, the handle assembly; and the locking collar is guided to the first position and between the first position and the second position by a groove in the handle assembly mating with a member carried by the locking collar. And a surgical device comprising: a handle assembly comprising a rotatable drive shaft; a removable handle assembly adapter for connection to the handle assembly, the removable handle assembly adapter comprising a rotatable transmission shaft for connection to the rotatable drive shaft of the handle assembly; and a removable nosepiece assembly for connection to the removable handle assembly adapter and for selectively securing the shaft of a working element to the rotatable transmission shaft of the removable handle assembly adapter; wherein the removable handle assembly adapter and the removable nosepiece assembly each comprise a locking collar; and wherein the removable handle assembly adapter and the handle assembly each comprise a connector assembly, the connector assembly comprising: a housing comprising an opening; a collet sleeve disposed within the opening and connected to an input shaft, the collet sleeve comprising a lumen for receiving an output shaft; a locking element movable relative to the collet sleeve between (i) a locked position in which the output shaft is secured to the collet sleeve, and (ii) an unlocked position in which the output shaft is not secured to the collet sleeve; and a cam element movable relative to the collet sleeve between (i) a first position in which the locking element is free to assume its unlocked position, and (ii) a second position in which the cam element cams the locking element into the locked position; such that movement of the locking collar causes the cam element to move between the first position and the second position.

US Patent:

20150313610, Nov 5, 2015

Filed:

Apr 30, 2015

Appl. No.:

14/700308

Inventors:

- Southborough MA, US
Jay A. Casey - Memphis TN, US
Peter Y. Wong - Arlington TN, US
Jesse Conrad - Cordova TN, US

International Classification:

A61B 17/16
B23B 31/20

Abstract:

A surgical device comprising: a handle assembly; a locking collar; and a set of replaceable bits that load along an axis into the handle assembly; wherein the locking collar is fully removable from the handle assembly, the locking collar loads axially to a first position, and the locking collar rotates between the first position and a second position; wherein, in the first position, the locking collar is free to be axially removed from the handle assembly and the replaceable bits are free to be loaded or unloaded from the handle assembly; wherein, in the second position, the locking collar is prevented from axial movement relative to the handle assembly and the replaceable bits are prevented from being received within, or removed from, the handle assembly; and the locking collar is guided to the first position and between the first position and the second position by a groove in the handle assembly mating with a member carried by the locking collar. And a surgical device comprising: a handle assembly comprising a rotatable drive shaft; a removable handle assembly adapter for connection to the handle assembly, the removable handle assembly adapter comprising a rotatable transmission shaft for connection to the rotatable drive shaft of the handle assembly; and a removable nosepiece assembly for connection to the removable handle assembly adapter and for selectively securing the shaft of a working element to the rotatable transmission shaft of the removable handle assembly adapter; wherein the removable handle assembly adapter and the removable nosepiece assembly each comprise a locking collar; and wherein the removable handle assembly adapter and the handle assembly each comprise a connector assembly, the connector assembly comprising: a housing comprising an opening; a collet sleeve disposed within the opening and connected to an input shaft, the collet sleeve comprising a lumen for receiving an output shaft; a locking element movable relative to the collet sleeve between (i) a locked position in which the output shaft is secured to the collet sleeve, and (ii) an unlocked position in which the output shaft is not secured to the collet sleeve; and a cam element movable relative to the collet sleeve between (i) a first position in which the locking element is free to assume its unlocked position, and (ii) a second position in which the cam element cams the locking element into the locked position; such that movement of the locking collar causes the cam element to move between the first position and the second position.

US Patent:

20150313612, Nov 5, 2015

Filed:

Apr 30, 2015

Appl. No.:

14/700336

Inventors:

- Southborough MA, US
Jay A. Casey - Memphis TN, US
Peter Y. Wong - Arlington TN, US
Jesse Conrad - Cordova TN, US

International Classification:

A61B 17/16

Abstract:

A surgical device comprising: a handle assembly; a locking collar; and a set of replaceable bits that load along an axis into the handle assembly; wherein the locking collar is fully removable from the handle assembly, the locking collar loads axially to a first position, and the locking collar rotates between the first position and a second position; wherein, in the first position, the locking collar is free to be axially removed from the handle assembly and the replaceable bits are free to be loaded or unloaded from the handle assembly; wherein, in the second position, the locking collar is prevented from axial movement relative to the handle assembly and the replaceable bits are prevented from being received within, or removed from, the handle assembly; and the locking collar is guided to the first position and between the first position and the second position by a groove in the handle assembly mating with a member carried by the locking collar. And a surgical device comprising: a handle assembly comprising a rotatable drive shaft; a removable handle assembly adapter for connection to the handle assembly, the removable handle assembly adapter comprising a rotatable transmission shaft for connection to the rotatable drive shaft of the handle assembly; and a removable nosepiece assembly for connection to the removable handle assembly adapter and for selectively securing the shaft of a working element to the rotatable transmission shaft of the removable handle assembly adapter; wherein the removable handle assembly adapter and the removable nosepiece assembly each comprise a locking collar; and wherein the removable handle assembly adapter and the handle assembly each comprise a connector assembly, the connector assembly comprising: a housing comprising an opening; a collet sleeve disposed within the opening and connected to an input shaft, the collet sleeve comprising a lumen for receiving an output shaft; a locking element movable relative to the collet sleeve between (i) a locked position in which the output shaft is secured to the collet sleeve, and (ii) an unlocked position in which the output shaft is not secured to the collet sleeve; and a cam element movable relative to the collet sleeve between (i) a first position in which the locking element is free to assume its unlocked position, and (ii) a second position in which the cam element cams the locking element into the locked position; such that movement of the locking collar causes the cam element to move between the first position and the second position.

US Patent:

20150133922, May 14, 2015

Filed:

Nov 17, 2014

Appl. No.:

14/542798

Inventors:

- Southborough MA, US
Jay A. Casey - Memphis TN, US
Peter Y. Wong - Arlington TN, US
Allen C. Palmer - Arlington TN, US

Assignee:

Gyrus ACMI, Inc. d.b.a. Olympus Surgical Technologies America - Southborough MA

International Classification:

A61B 18/14
A61B 17/32

US Classification:

606 45, 29854

Abstract:

A device comprising: a handpiece having one or more attachment ports; a tubeset having one or more attachment features for connecting the tubeset to the one or more attachment ports in the handpiece; a removable tip having an attachment arm for attaching to the one or more attachment ports in the handpiece; wherein the device comprises one or more of the following: the handpiece includes an attachment port that attaches the handpiece to an active lead and a return lead and the device is adapted to use only the active lead or both leads so that the device can switch between bi-polar energy and mono-polar energy; the tubeset has one or more fluid conduits that are in fluid communication with the removable tip, wherein the removable tip is located at a distal end of the device; and the handpiece connects to one or more electrical input lines; the tubeset connects to one or more fluid lines, and the removable tip is free of direct connection to both the one or more electrical input lines and the one or more fluid lines.

US Patent:

20150073405, Mar 12, 2015

Filed:

Nov 17, 2014

Appl. No.:

14/542773

Inventors:

- Southborough MA, US
Jay A. Casey - TN US, US
Peter Y. Wong - Arlington TN, US
Allen C. Palmer - Arlington TN, US

Assignee:

Gyrus ACMI, Inc. d.b.a. Olympus Surgical Technologies America - Southborough MA

International Classification:

A61B 18/14
A61B 19/00
A61B 18/12

US Classification:

606 34, 295921

Abstract:

A device comprising: a handpiece having one or more attachment ports; a tubeset having one or more attachment features for connecting the tubeset to the one or more attachment ports in the handpiece; a removable tip having an attachment arm for attaching to the one or more attachment ports in the handpiece; wherein the device comprises one or more of the following: the handpiece includes an attachment port that attaches the handpiece to an active lead and a return lead and the device is adapted to use only the active lead or both leads so that the device can switch between bi-polar energy and mono-polar energy; the tubeset has one or more fluid conduits that are in fluid communication with the removable tip, wherein the removable tip is located at a distal end of the device; and the handpiece connects to one or more electrical input lines; the tubeset connects to one or more fluid lines, and the removable tip is free of direct connection to both the one or more electrical input lines and the one or more fluid lines.

US Patent:

20140155889, Jun 5, 2014

Filed:

Mar 14, 2013

Appl. No.:

13/804308

Inventors:

Jay A. Casey - Memphis TN, US
Peter Y. Wong - Arlington TN, US
Allen C. Palmer - Arlington TN, US

Assignee:

GYRUS ACMI, INC., d/b/a Olympus Surgical Technologies America - Southborough MA

International Classification:

A61B 18/14

US Classification:

606 42

Abstract:

A device comprising: a handpiece having one or more attachment ports; a tubeset having one or more attachment features for connecting the tubeset to the one or more attachment ports in the handpiece; a removable tip having an attachment arm for attaching to the one or more attachment ports in the handpiece; wherein the device comprises one or more of the following: the handpiece includes an attachment port that attaches the handpiece to an active lead and a return lead and the device is adapted to use only the active lead or both leads so that the device can switch between bi-polar energy and mono-polar energy; the tubeset has one or more fluid conduits that are in fluid communication with the removable tip, wherein the removable tip is located at a distal end of the device; and the handpiece connects to one or more electrical input lines; the tubeset connects to one or more fluid lines, and the removable tip is free of direct connection to both the one or more electrical input lines and the one or more fluid lines.
