Phillip A Armstrong

US Patent:

7007932, Mar 7, 2006

Filed:

Jul 25, 2003

Appl. No.:

10/627044

Inventors:

Phillip Andrew Armstrong - Orefield PA, US
Patrick Alan Houghton - Emmaus PA, US
James William Meehan - Dallas PA, US
George Amir Meski - Allentown PA, US

Assignee:

Air Products and Chemicals, Inc. - Allentown PA

International Classification:

B01F 3/04

US Classification:

261 97, 261110

Abstract:

An apparatus for collecting and redistributing a flow of a liquid descending in an exchange column containing a layer of structured packing and having a longitudinal axis, a cross-sectional area, and an inner wall having an inner perimeter, includes: a wall-flow collector located above the layer of structured packing, the wall-flow collector having an outer perimeter adjacent the inner perimeter of the inner wall and being adapted to collect at least a portion of the liquid descending on or near the inner wall of the exchange column; a transmission means for transmitting at least a portion of the collected liquid collected by the wall-flow collector toward the longitudinal axis a substantial distance across the cross-sectional area of the exchange column; and a dispensing means for dispensing at least a portion of the portion of the collected liquid from the transmission means to the layer of structured packing.

US Patent:

7179323, Feb 20, 2007

Filed:

Aug 6, 2003

Appl. No.:

10/635695

Inventors:

VanEric Edward Stein - Allentown PA, US
Michael Francis Carolan - Allentown PA, US
Christopher M. Chen - Allentown PA, US
Phillip Andrew Armstrong - Orefield PA, US
Harold W. Wahle - North Canton OH, US
Theodore R. Ohrn - Alliance OH, US
Kurt E. Kneidel - Alliance OH, US
Keith Gerard Rackers - Louisville OH, US
James Erik Blake - Uniontown OH, US
Shankar Nataraj - Allentown PA, US
Rene Hendrik Elias van Doorn - Obersulm-Willsbach, DE
Merrill Anderson Wilson - West Jordan UT, US

Assignee:

Air Products and Chemicals, Inc. - Allentown PA

International Classification:

B01D 53/22

US Classification:

95 54, 96 7, 96 9

Abstract:

An ion transport membrane system comprising (a) a pressure vessel having an interior, an exterior, an inlet, and an outlet; (b) a plurality of planar ion transport membrane modules disposed in the interior of the pressure vessel and arranged in series, each membrane module comprising mixed metal oxide ceramic material and having an interior region and an exterior region, wherein any inlet and any outlet of the pressure vessel are in flow communication with exterior regions of the membrane modules; and (c) one or more gas manifolds in flow communication with interior regions of the membrane modules and with the exterior of the pressure vessel. The ion transport membrane system may be utilized in a gas separation device to recover oxygen from an oxygen-containing gas or as an oxidation reactor to oxidize compounds in a feed gas stream by oxygen permeated through the mixed metal oxide ceramic material of the membrane modules.

US Patent:

7335247, Feb 26, 2008

Filed:

Jan 29, 2007

Appl. No.:

11/699145

Inventors:

VanEric Edward Stein - Allentown PA, US
Michael Francis Carolan - Allentown PA, US
Christopher M. Chen - Allentown PA, US
Phillip Andrew Armstrong - Orefield PA, US
Harold W. Wahle - North Canton OH, US
Theodore R. Ohrn - Alliance OH, US
Kurt E. Kneidel - Alliance OH, US
Keith Gerard Rackers - Louisville OH, US
James Erik Blake - Uniontown OH, US
Shankar Nataraj - Allentown PA, US
Rene Hendrik Elias van Doorn - Obersulm-Willsbach, DE
Merrill Anderson Wilson - West Jordan UT, US

Assignee:

Air Products and Chemicals, Inc. - Allentown PA

International Classification:

B01D 53/22

US Classification:

96 7, 95 54

Abstract:

An ion transport membrane system comprising (a) a pressure vessel having an interior, an exterior, an inlet, and an outlet; (b) a plurality of planar ion transport membrane modules disposed in the interior of the pressure vessel and arranged in series, each membrane module comprising mixed metal oxide ceramic material and having an interior region and an exterior region, wherein any inlet and any outlet of the pressure vessel are in flow communication with exterior regions of the membrane modules; and (c) one or more gas manifolds in flow communication with interior regions of the membrane modules and with the exterior of the pressure vessel. The ion transport membrane system may be utilized in a gas separation device to recover oxygen from an oxygen-containing gas or as an oxidation reactor to oxidize compounds in a feed gas stream by oxygen permeated through the mixed metal oxide ceramic material of the membrane modules.

US Patent:

8114193, Feb 14, 2012

Filed:

Jan 18, 2008

Appl. No.:

12/016667

Inventors:

VanEric Edward Stein - Allentown PA, US
Michael Francis Carolan - Allentown PA, US
Christopher M. Chen - Allentown PA, US
Phillip Andrew Armstrong - Orefield PA, US
Harold W. Wahle - North Canton OH, US
Theodore R. Ohrn - Alliance OH, US
Kurt E. Kneidel - Alliance OH, US
Keith Gerard Rackers - Louisville OH, US
James Erik Blake - Uniontown OH, US
Shankar Nataraj - Allentown PA, US
Rene Hendrik Elias Van Doorn - Obersulm-Willsbach, DE
Merrill Anderson Wilson - West Jordan UT, US

Assignee:

Air Products and Chemicals, Inc. - Allentown PA

International Classification:

B01D 53/22

US Classification:

95 54, 96 4, 96 7

Abstract:

An ion transport membrane system comprising (a) a pressure vessel having an interior, an exterior, an inlet, and an outlet; (b) a plurality of planar ion transport membrane modules disposed in the interior of the pressure vessel and arranged in series, each membrane module comprising mixed metal oxide ceramic material and having an interior region and an exterior region, wherein any inlet and any outlet of the pressure vessel are in flow communication with exterior regions of the membrane modules; and (c) one or more gas manifolds in flow communication with interior regions of the membrane modules and with the exterior of the pressure vessel. The ion transport membrane system may be utilized in a gas separation device to recover oxygen from an oxygen-containing gas or as an oxidation reactor to oxidize compounds in a feed gas stream by oxygen permeated through the mixed metal oxide ceramic material of the membrane modules.

US Patent:

20110067405, Mar 24, 2011

Filed:

Sep 18, 2009

Appl. No.:

12/562295

Inventors:

Phillip A. Armstrong - Allentown PA, US
Elia P. Demetri - Westford MA, US

Assignee:

CONCEPTS ETI, INC. - White River Junction VT
AIR PRODUCTS AND CHEMICALS, INC. - Allentown PA

International Classification:

F02C 1/00
B01D 53/22

US Classification:

60752, 96 4, 95 54

Abstract:

Integrated gas turbine combustion engine and ion transport membrane system comprising a gas turbine combustion engine including a compressor with a compressed oxygen-containing gas outlet; a combustor comprising an outer shell, a combustion zone in flow communication with the compressed oxygen-containing gas outlet, and a dilution zone in flow communication with the combustion zone and having one or more dilution gas inlets; and a gas expander. The system includes an ion transport membrane oxygen recovery system with an ion transport membrane module that includes a feed zone, a permeate zone, a feed inlet to the feed zone in flow communication with the compressed oxygen-containing gas outlet of the compressor, a feed zone outlet, and a permeate withdrawal outlet from the permeate zone. The feed zone outlet of the membrane module is in flow communication with any of the one or more dilution gas inlets of the combustor dilution zone.

US Patent:

60860553, Jul 11, 2000

Filed:

Oct 5, 1998

Appl. No.:

9/166374

Inventors:

Phillip Andrew Armstrong - Orefield PA
Kenneth William Kovak - Macungie PA
James William Meehan - Shavertown PA

Assignee:

Air Products and Chemicals, Inc. - Allentown PA

International Classification:

B01F 304

US Classification:

261 96

Abstract:

A combined liquid/vapor distributor and method of assembly are disclosed together with a method for collection and distribution of a liquid and a vapor in an exchange column. The combined liquid/vapor distributor is an apparatus for distributing a liquid and a vapor to or from a packing in an exchange column. The apparatus includes a distributor and a deck above and adjacent the distributor. The distributor has at least one vapor riser, which has generally parallel spaced apart upright walls and an open top and an open bottom opposite the open top. The distributor also has at least one liquid trough adjacent the vapor riser. The liquid trough has an open top and a floor having at least one aperture. The floor is opposite the open top of the liquid trough and is attached to at least one wall of the adjacent vapor riser. The deck has a top and a bottom and at least one aperture vertically aligned with the open top of the vapor riser and at least one aperture vertically aligned with the open top of the liquid trough.

US Patent:

61491365, Nov 21, 2000

Filed:

Jan 20, 1998

Appl. No.:

9/009093

Inventors:

Phillip Andrew Armstrong - Orefield PA
Mohammad Ali Kalbassi - Walton-on-Thames, GB
Derek Miller - Guildford, GB

Assignee:

Air Products and Chemicals, Inc. - Allentown PA

International Classification:

B01F 304

US Classification:

261 19

Abstract:

A liquid distributor for a packed liquid-vapor contact column includes a header tank; a liquid distribution plate having vapor riser passages and a multiplicity of discrete reservoir cells each having an aperture for flow of liquid therefrom into the column; and conduits for feeding liquid from the header tank into each cell. The liquid distribution plate preferably has a uniform criss-cross structure with alternating vapor riser passages and reservoir cells of identical shape and size. The conduits may have two or more sections each feeding a discrete group of reservoir cells from a location of the header tank at an elevation spaced from that of the other section(s). The distributor compensates for column sway or tilt when mounted on, for example, a ship.

US Patent:

59842822, Nov 16, 1999

Filed:

Jan 20, 1998

Appl. No.:

9/009094

Inventors:

Phillip Andrew Armstrong - Orefield PA
Mohammad Ali Kalbassi - Walton-on-Thames, GB
Derek Miller - Guildford, GB

Assignee:

Air Products and Chemicals, Inc. - Allentown PA

International Classification:

B01F 304

US Classification:

2611122

Abstract:

A liquid-vapor contact column is packed with at least one layer formed of a plurality of structured packing sheets orientated to provide liquid-vapor contact in the axial direction of the column and arranged so that, viewed in the axial direction of the column, packing sheets in the body of the layer are in one or more sections in which at least one band surrounds a central core, said band being formed of segments in which the packing sheets in each segment extend rectilinearly in a different direction to those in the adjacent segments in the same band. The packing sheets in the body of the or each layer can be arranged in a plurality of abutting sections or in a single section.
