Bruce Allen Thompson - Fairport NY, US Frank Albert Porter - Penfield NY, US Michael J. Linder - Walworth NY, US William Matthew Harney - Rush NY, US Robert J. Rinefierd - Fairport NY, US
Assignee:
Xerox Corporation - Norwalk CT
International Classification:
B65H 39/10
US Classification:
271301, 271304, 271186, 399364
Abstract:
A dual path, single reversing roll inverter driven by a single actuator includes a single reversing roller with two, diametrically opposed idler rollers. The configuration of the reversing roller and idler rollers forms a first nip and a second nip that are alternately used to accept sequential sheets from a paper path. The first and second nips discharge the sheets into respective first and second inverting paths. A method for inverting sheets using the dual path, single reversing roll inverter includes rotating the roller in a first direction to direct a first sheet through the first nip. The roller is then rotated in a second direction opposite the first direction to direct the first sheet from the first nip and into the first inverting path and to simultaneously direct a second sheet into the second nip. A gate alternately directs the sequential sheets into the first and second nips.
Frank Albert Porter - Penfield NY, US Michael J. Linder - Walworth NY, US William Matthew Harney - Rush NY, US Robert Rinefierd - Fairport NY, US
Assignee:
Xerox Corporation - Norwalk CT
International Classification:
B65H 29/00
US Classification:
271186
Abstract:
A sheet inverter apparatus improves the handling capabilities of high speed printers and copiers. The sheet inverter apparatus includes a rotatable support having an axis of rotation and at least first and second arms radiating outwardly from the axis of rotation. First and second nip assemblies are is mounted to the first and second arms respectively. The support is rotatable to adjust positions of the first and second nips about the axis of rotation. Advantageously, with this arrangement, the support is adjustable so as to permit the first and second nips to receive sheets of paper at one location, be positionally adjusted with the sheets of paper moving therewith, and located at a second location so as to deliver the paper to an outlet feed path. This positional adjustment allows for inversion of the paper.
Termination Frame Assembly With Protection From Emi From Field Wiring And Rack For Same
A termination frame assembly mounts signal conditioner circuit boards for a data acquisition system individually on a frame with an electromagnetic interference (EMI) barrier extending along the front edge and bending back over the circuit board and then out to form an integral trough through which the field wiring is routed to field terminals on terminal strips in the front face of the barrier. The circuit board is installed from the rear with a guide block, keyed to accept only a selected one of a family of boards, lifting the center of the leading edge to align edge connectors with connectors on the rear of the terminal strips. A plurality of the termination frame assemblies are stacked between, and secured to the front and rear legs of, confronting U-shaped channel members with the field wiring routed vertically along the front legs to the horizontal troughs and with power supply and test signal busses routed along one rear leg and connected by leads to plugs on the termination frame assemblies which engage terminations on the leading edge of the circuit board as it is installed. Additional leads on these plugs are connected to complete a series circuit only when all circuit boards are installed. The stacked termination frame assemblies are mounted in a cabinet with the field terminals and the field wiring in the recessed troughs accessible through a rear door and with the circuit boards which are connected to other equipment in the cabinet by connectors on their trailing edges accessible through the front door.
Power Circuit Breaker With Air Gap Between Molded Insulative Casing And Grounded Barrier Insulating Operating Mechanism
Francois J. Marchand - Pittsburgh PA Norman Davies - Irwin PA Robert J. Rinefierd - Irwin PA Glenn A. Calhoon - Aliquippa PA Walter O. Jenkins - Crafton PA
Assignee:
Eaton Corporation - Cleveland OH
International Classification:
H01H 902
US Classification:
335202
Abstract:
A compact power circuit breaker has a molded insulative casing providing the structural support and electrical isolation for the pole mechanisms mounted in cavities in the casing and the operating mechanism mounted to the front of the casing. A grounded barrier between the pole mechanisms and the operating mechanism protects the operator actuating push buttons controlling the operating mechanism and accessible through a molded insulative cover. Preferably, the grounded barrier is sandwiched between a rear section of the molded casing containing the pole cavities and a forward section to which the operating mechanism is secured. The grounded barrier is connected to an electrically conductive pan extending under the molded insulative casing which also houses electrically grounded linkages coupling the operating mechanism to the vacuum interrupters of the pole mechanisms. A vented air gap between the rear section of the molded insulative casing and the grounded barrier minimizes erosion of the molded insulative casing in the event of an arc penetrating the casings to the grounded barrier.
Round Linear Actuator Utilizing Flat Permanent Magnets
Glenn Arthur Calhoon - Aliquippa PA Paul Thomas Bottegal - Lower Burrell PA Robert Joseph Rinefierd - Irwin PA Francois Jean Marchand - Pittsburgh PA Robert Michael Slepian - Murrysville PA
Assignee:
Eaton Corporation - Cleveland OH
International Classification:
H02K 4100
US Classification:
310 12, 310 30
Abstract:
A linear actuator which includes a housing assembly, a shaft assembly disposed within the housing assembly, a plurality of flat magnets disposed within said housing about said shaft, and a structure to support the magnets. Because the magnets are flat magnets, the components that support the magnets may be machined with tolerances that virtually eliminate the air gap between the magnets and the support structures.
- Norwalk CT, US Frank Albert Porter - Penfield NY, US Michael J. Linder - Walworth NY, US William Matthew Harney - Rush NY, US Robert Rinefierd - Fairport NY, US
Assignee:
Xerox Corporation - Norwalk CT
International Classification:
B65H 85/00 B65H 5/26
US Classification:
271225, 271186
Abstract:
Provided herein is sheet inverter apparatus which includes a diverter gate which diverts the sheet to one of at least two paths, a first paper path, and a second paper path. The first and second path each include a rotatable nip assembly, the rotatable nip assembly including a nip drive roll and a nip idler roll positioned so as to define a nip therebetween, the nip serving as a rotatable axis around which the nip drive roll and the nip idler roll rotate to invert the sheet.
