Samuel Martin Harvey

US Patent:

41251970, Nov 14, 1978

Filed:

May 19, 1977

Appl. No.:

5/798710

Inventors:

Samuel E. Harvey - Knoxville TN
James S. Whitehead - Maryville TN
Paul L. Goranson - Knoxville TN

Assignee:

Carrier Corporation - Syracuse NY

International Classification:

B65G 6504

US Classification:

214310

Abstract:

An automated refuse container discharge station is disclosed in which a refuse container is emptied such that its volume decreases as an essentially constant function of time. The unloading station includes a support assembly on which a carriage assembly is adapted for longitudinally sliding motion. The carrier assembly includes container opening apparatus at one end and container discharging apparatus at the other end. The carriage assembly also includes apparatus for unlatching a container tailgate portion and releasably securing the container to the carriage. A hydraulic cylinder advances the carriage assembly with respect to the support assembly and hydraulically damps movement of the carriage and container at the end of the advancing stroke. The carriage assembly includes an hydraulic discharge cylinder which may be intermittently advanced into the container. Part of the discharge cylinder is supported by guides carried by the carriage and aligned guides carried by the container.

US Patent:

41472640, Apr 3, 1979

Filed:

May 19, 1977

Appl. No.:

5/798734

Inventors:

Samuel E. Harvey - Knoxville TN
James S. Whitehead - Maryville TN
Paul L. Goranson - Knoxville TN

Assignee:

Carrier Corporation - Syracuse NY

International Classification:

B65G 6504

US Classification:

414411

Abstract:

An automated refuse container discharge station is disclosed in which a refuse container is emptied such that its volume decreases as an essentially constant function of time. The unloading station includes a support assembly on which a carriage assembly is adapted for longitudinally sliding motion. The carriage assembly includes container opening apparatus at one end and container discharging apparatus at the other end. The carriage assembly also includes apparatus for unlatching a container tailgate portion and releasably securing the container to the carriage. A hydraulic cylinder advances the carriage assembly with respect to the support assembly and hydraulically damps movement of the carriage and container at the end of the advancing stroke. The carriage assembly includes an hydraulic discharge cylinder which may be intermittently advanced into the container. Part of the discharge cylinder is supported by guides carried by the carriage and aligned guides carried by the container.

US Patent:

40944247, Jun 13, 1978

Filed:

Dec 17, 1975

Appl. No.:

5/641524

Inventors:

Samuel E. Harvey - Knoxville TN
James Stephen Whitehead - Maryville TN
Paul L. Goranson - Knoxville TN

Assignee:

Carrier Corporation - Syracuse NY

International Classification:

B65G 6922

US Classification:

214304

Abstract:

An automated refuse container discharge station is disclosed in which a refuse container is emptied such that its volume decreases as an essentially constant function of time. The unloading station includes a support assembly on which a carriage assembly is adapted for longitudinally sliding motion. The carriage assembly includes container opening apparatus at one end and container discharging apparatus at the other end. The carriage assembly also includes apparatus for unlatching a container tailgate portion and releasably securing the container to the carriage. A hydraulic cylinder advances the carriage assembly with respect to the support assembly and hydraulically damps movement of the carriage and container at the end of the advancing stroke. The carriage assembly includes an hydraulic discharge cylinder which may be intermittently advanced into the container. Part of the discharge cylinder is supported by guides carried by the carriage and aligned guides carried by the container.

US Patent:

41051297, Aug 8, 1978

Filed:

May 19, 1977

Appl. No.:

5/798508

Inventors:

Samuel E. Harvey - Knoxville TN
James S. Whitehead - Maryville TN
Paul L. Goranson - Knoxville TN

Assignee:

Carrier Corporation - Syracuse NY

International Classification:

B60P 100

US Classification:

214152

Abstract:

An automated refuse container discharge station is disclosed in which a refuse container is emptied such that its volume decreases as an essentially constant function of time. The unloading station includes a support assembly on which a carriage assembly is adapted for longitudinally sliding motion. The carriage assembly includes container opening apparatus at one end and container discharging apparatus at the other end. The carriage assembly also includes apparatus for unlatching a container tailgate portion and releasably securing the container to the carriage. A hydraulic cylinder advances the carriage assembly with respect to the support assembly and hydraulically damps movement of the carriage and container at the end of the advancing stroke. The carriage assembly includes an hydraulic discharge cylinder which may be intermittently advanced into the container. Part of the discharge cylinder is supported by guides carried by the carriage and aligned guides carried by the container.

US Patent:

40346498, Jul 12, 1977

Filed:

Oct 2, 1973

Appl. No.:

5/402714

Inventors:

Samuel E. Harvey - Knoxville TN
Harvey W. Liberman - Knoxville TN
Steven C. Voorhees - Oak Ridge TN

Assignee:

Carrier Corporation - Syracuse NY

International Classification:

F15B 1120
F15B 1122

US Classification:

91412

Abstract:

Apparatus for automatically leveling the forks of vertically moveable hoist arms. In a typical embodiment, the arms are used on refuse collection vehicles for lifting and dumping detachable containers into the body of the vehicle. The arms are pivotally mounted at one end on the vehicle and the opposite ends of the arms has fork devices for engaging brackets on opposite end walls of the detachable containers. Swinging movement of the arms and of the forks is accomplished by means of hydraulic cylinders or rams. A hydraulic pump supplies fluid under pressure to the arm cylinders for raising the arms. A portion of the fluid is conducted to the fork cylinder by means of a gear or vane type flow divider, so that the rate of extension of the piston in each fork cylinder is at a predetermined ration of the displacement of the arm piston. This causes the forks to swing downwardly at a predetermined rate while the arms are being raised toward a dumping position, thereby maintaining the container approximately horizontal until it is in position to be inverted for dumping.
