Satish D Savant

US Patent:

7834500, Nov 16, 2010

Filed:

Aug 29, 2008

Appl. No.:

12/230527

Inventors:

Satish Dattatraya Savant - Peoria IL, US

Assignee:

Caterpillar Inc - Peoria IL

International Classification:

H02K 7/10
H02K 1/16
H02K 9/197

US Classification:

310 78, 310 61, 310 75 R, 310 83, 310 99, 290 31, 290 36 R, 192 566, 464 46, 464 47, 464 48, 74333, 74640

Abstract:

A generator system is disclosed. The generator system includes an input gear, a gear train coupled to the input gear, and a clutch associated with the input gear, wherein the clutch is exposed to the gear train.

US Patent:

7950969, May 31, 2011

Filed:

Nov 24, 2009

Appl. No.:

12/624744

Inventors:

Satish D. Savant - Peoria IL, US

Assignee:

Caterpillar Inc. - Peoria IL

International Classification:

H01R 9/22

US Classification:

439722

Abstract:

The present disclosure is directed to a terminal assembly member for electrically connecting output leads to external systems and equipment, including a one piece insulating body formed from high-pressure molten plastic/nylon, adapted for mounting to an external portion of a generator housing; one or more conductive inserts over-molded within the one piece insulated body, the conductive inserts having at least one threaded bore for receiving a bolt; and one or more bronze alloy lug structures over-molded within the one piece insulated body, the one or more lug structures having a generally L-shaped geometry and a plurality of bores adapted for attaching terminal ring carriers.

US Patent:

7965002, Jun 21, 2011

Filed:

Oct 7, 2008

Appl. No.:

12/246513

Inventors:

Satish D. Savant - Peoria IL, US

Assignee:

Caterpillar Inc. - Peoria IL

International Classification:

H05K 7/20

US Classification:

310 52, 310 58

Abstract:

The present disclosure is directed to a fluid-cooled housing for an electric device having an outer surface and an inner surface, the inner surface defining, at least in part, a housing cavity having a longitudinal axis, an end wall continuous with the inner surface. The inner surface having a plurality of core print openings along the longitudinal axis, and a helical conduit integrated within the housing between the outer and inner surfaces along the axis formed from a helical coil core having two or more laterally extending tabs which form the core print in two or more planes.

US Patent:

8067865, Nov 29, 2011

Filed:

Oct 28, 2008

Appl. No.:

12/259328

Inventors:

Satish D. Savant - Peoria IL, US

Assignee:

Caterpillar Inc. - Peoria IL

International Classification:

H02K 9/00
H02K 9/08

US Classification:

310 52, 310 54, 310 57, 310 58

Abstract:

The present disclosure, in one form, provides an electric motor/generator low hydraulic resistance cooling mechanism including a hollow cooling stator case having an inner and outer coaxial surface. The inner surface defines a generally cylindric cavity for receiving a stator in heat transference contact with the inner surface. The outer surface has integrated spiral groove cooling passages that are defined by filleted rectangular cross sections.

US Patent:

8074534, Dec 13, 2011

Filed:

Jul 30, 2007

Appl. No.:

11/830278

Inventors:

Satish Savant - Peoria IL, US
David Fee - Groveland IL, US
Bradford Kough - Metamora IL, US
Jonathan Baumann - Peoria IL, US
Perry Cruce - Marquette Hts. IL, US
Matthew Dames - Brimfield IL, US

Assignee:

Caterpillar Inc. - Peoria

International Classification:

H02K 7/02
F16C 15/00
B23Q 11/12
F16N 39/00

US Classification:

745721, 745722, 184 614, 184 621

Abstract:

A flywheel includes a hub portion concentrically defined around a center of the flywheel. A body portion located peripherally around the hub portion has a driver-side face and a driven-side face. A plurality of passageways in the body portion extend through the flywheel and fluidly connect the driver-side face with the driven-side face. Each of the plurality of passageways is adapted to receive a flow of lubricant spilling onto the driver-side of the body portion when the flywheel is rotating, and to expel lubricant out of the driven-side face of the body portion.

US Patent:

20080191492, Aug 14, 2008

Filed:

Feb 9, 2007

Appl. No.:

11/704814

Inventors:

Satish Savant - Peoria IL, US
Bradford A. Kough - Metamora IL, US
David M. Fee - Groveland IL, US
Jonathan Baumann - Peoria IL, US
Matthew Dames - Brimfield IL, US

International Classification:

F02D 35/00
B60K 6/20
G05D 17/02

US Classification:

290 40 A, 180 652, 700287

Abstract:

A machine and electrical power system includes a generator having a speed range that includes a resonance speed associated with resonance vibrations of the system. A drive coupling is disposed between the generator and an engine configured to rotate the generator and is further configured to transmit torque from the engine to the generator, the drive coupling being configured to allow relative slip between first and second elements when the generator is rotated at its resonance speed. A machine operation method includes rotating a generator with an engine, and generating resonance vibrations of at least one of the engine and the generator by rotating the generator at a resonance speed. The method further includes inhibiting transmitting resonance vibrations between the generator and the engine by allowing relative rotational slip within a drive coupling disposed between the engine and the generator.

US Patent:

20090102298, Apr 23, 2009

Filed:

Oct 19, 2007

Appl. No.:

11/975612

Inventors:

Satish D. Savant - Peoria IL, US
David M. Fee - Groveland IL, US

Assignee:

Caterpillar Inc. - Peoria IL

International Classification:

H02K 9/00
H05K 7/20

US Classification:

310 52, 361701

Abstract:

A fluid-cooled electric device such as a generator, alternator or motor is provided with a housing that includes an outer surface defining an exterior of the device and an inner surface that defines a housing cavity with a longitudinal axis, and which may have an end wall enclosing one end of the housing cavity wherein the end wall is continuous with the inner surface. Integral to the housing is a helical cooling conduit, which may have a rectangular configuration, disposed along the axis between the inner and outer surfaces of the housing.

US Patent:

20100105514, Apr 29, 2010

Filed:

Oct 28, 2008

Appl. No.:

12/289434

Inventors:

Matthew William Dames - Brimfield IL, US
Satish Dattatraya Savant - Peoria IL, US

International Classification:

F16H 57/10

US Classification:

475257

Abstract:

A drive assembly for use with a mobile machine is disclosed. The drive assembly may have a flywheel, a planet carrier having a plurality of planet gears, and a damper operatively connecting the flywheel to the planet carrier. The drive assembly may also have a sun gear configured to mesh with the plurality of planet gears, a ring gear configured to mesh with the plurality of planet gears, and a friction clutch configured to inhibit rotation of the ring gear when a torque of the drive assembly is less than a threshold value.
