Scott A Duncan

US Patent:

20210294081, Sep 23, 2021

Filed:

Mar 18, 2020

Appl. No.:

16/822272

Inventors:

- Mountain View CA, US
Albert Shane - Mountain View CA, US
YooJung Ahn - Mountain View CA, US
Jeffrey Du - San Jose CA, US
Scott Duncan - Sunnyvale CA, US
Choon Ping Chng - Los Altos CA, US
Cheng-Han Wu - Mountain View CA, US

International Classification:

G02B 13/14
B60R 1/00
G03B 17/02

Abstract:

The technology provides a camera module cover that prevents infrared light from leaking into the lens of an adjacent camera. The camera module cover can be used with in-vehicle environments, such as the passenger area and truck, as well as other indoor locations and places where infrared illumination is co-located with an optical camera system. An infrared illuminator unit is positioned adjacent to the camera, for instance in such a way that infrared light is evenly distributed or diffused around the camera lens. The camera module cover has a surface that includes an infrared-transparent material to promote even distribution of the infrared light. To avoid leakage into the camera lens, an infrared-opaque or otherwise blocking material is disposed within the cover so as to be between the infrared illuminator unit and the camera lens. The infrared-transparent and infrared-blocking materials may be formed as a single part via double injection molding.
