Sean P Gallagher

US Patent:

7516712, Apr 14, 2009

Filed:

Apr 20, 2007

Appl. No.:

11/789116

Inventors:

John F. O'Dea - Laurel MD, US
Robert W. Anderson - Alexandria VA, US
Sean M. Gallagher - Philadelphia PA, US
Ryan T. Hayleck - Fulton MD, US
Kellie L. Redcay - Pottstown PA, US
Stuart G. Ullman - Kensington MD, US

Assignee:

The United States of America as represented by the Secretary of the Navy - Washington DC

International Classification:

B63B 39/00
B63B 21/00

US Classification:

114122, 1142301, 114231

Abstract:

A vertical damping system for a plurality of water vessels for diminishing the relative vertical movement between two or more water vessels moored in a skin-to-skin orientation. The vertical damping system may include one or more vertical damping devices, each device pivotally connected to a side portion of a first vessel and detachably connecting to a side portion of a second vessel. The vertical damping device may be a piston/cylinder arrangement and the damping system may involve more than two water vessels. The vertical damping system counteracts the effect of roll motion on water vessels, thereby enabling ship-to-ship functions such as cargo loading and the like.

US Patent:

7621230, Nov 24, 2009

Filed:

Apr 20, 2007

Appl. No.:

11/789125

Inventors:

Robert W. Anderson - Alexandria VA, US
Stuart G. Ullman - Kensington MD, US
Kellie L. Redcay - Pottstown PA, US
Ryan T. Hayleck - Fulton MD, US
John F. O'Dea - Laurel MD, US
Sean M. Gallagher - Philadelphia PA, US
Christopher J. Doyle - Panama City Beach FL, US
Donald R. Jacobson - Virginia Beach VA, US

Assignee:

The United States of America as represented by the Secretary of the Navy - Washington DC

International Classification:

B63B 35/40

US Classification:

114258, 114259

Abstract:

A method and apparatus for cargo transfer at sea, more particularly, a flow-through vessel and related method for the at-sea and underway launching and loading of air-cushion vehicles. The vessel includes a hull having a forward end and an aft end, a continuous deck extending from the forward end to the aft end of the hull, a forward ramp attached to the continuous deck at the forward end of the hull, and an aft ramp attached to the continuous deck at the aft end of the hull. At least a portion of the continuous deck is uncovered and accessible from above the deck.

US Patent:

7793374, Sep 14, 2010

Filed:

Apr 20, 2007

Appl. No.:

11/788422

Inventors:

Robert W. Anderson - Alexandria VA, US
Sean M. Gallagher - Philadelphia PA, US
Kellie L. Redcay - Pottstown PA, US
Ryan T. Hayleck - Fulton MD, US
John F. O'Dea - Laurel MD, US
Stuart G. Ullman - Kensington MD, US

Assignee:

The United States of America as represented by the Secretary of the Navy - Washington DC

International Classification:

B63B 17/00

US Classification:

14 695, 114362

Abstract:

As typically embodied, the inventive ramp system for bridging between structures (e. g. , marine vessels) includes a hydraulic elevator device and a ramp unit. The ramp unit includes three adjoining planar members, the ramp member (the main ramp body) being pivotably connected at each end to one of the two platform members. The hydraulic elevator device includes the coaxial combination of a cylinder and a piston, the piston being translatable along and pivotable about the axis. The cylinder-piston combination is secured, axis vertical, to a first structure, with one of the ramp unit's platform members attached atop the piston. In order to position the other (unattached) platform member upon a selected (e. g. , horizontal) location of a second structure, the ramp unit is configurable in terms of the attached platform member's height, the ramp unit's horizontal rotation angle, and the respective vertical rotation angles of the ramp unit's two pivotable connections.

US Patent:

20030064507, Apr 3, 2003

Filed:

Jul 26, 2002

Appl. No.:

10/206841

Inventors:

Sean Gallagher - Claremont CA, US
David Dorris - Austin TX, US
Lawrence Dues - Chandler AZ, US
Alan De La Cerda - Chandler AZ, US
Norb Simonson - Mesa AZ, US
Clifford Anderson - Tempe AZ, US
Phillip Franciskovich - Phoenix AZ, US
Peter Kahn - Phoenix AZ, US

International Classification:

C12M001/34

US Classification:

435/287200, 435/006000, 422/099000

Abstract:

The present invention provides microfluidic systems comprising microfluidic chambers and mixers, and methods of use. The microfluidic chambers of the present invention comprise a flexible membrane which provides efficient mixing of the solution therein. The present invention also provides a microfluidic chamber in fluidic communication with a micro-disk and a microfluidic chamber comprising a shim such that and a contiguous gap is present between a sample fluid and the chamber membrane. The microfluidic systems find use in the decrease in time for reactions occurring therein.

US Patent:

20060208199, Sep 21, 2006

Filed:

Mar 18, 2005

Appl. No.:

11/083768

Inventors:

Sean Gallagher - Claremont CA, US
Soham Mehta - Upland CA, US

International Classification:

G01J 1/58

US Classification:

250458100

Abstract:

A luminescent calibration device () is provided with the luminescent calibration device () having a housing () with a surface (). The housing () has a length (), a width (), and a thickness (). The housing () having a luminescent standard () disposed on the housing (). A method for calibrating and normalizing luminescent data across a sample and to normalize data from day to day variations is provided.
