Stephen P Ward

US Patent:

20050028977, Feb 10, 2005

Filed:

Aug 6, 2003

Appl. No.:

10/636947

Inventors:

Stephen Ward - Cypress TX, US

International Classification:

E21B043/04

US Classification:

166278000, 166227000

Abstract:

Apparatus for gravel packing a wellbore interval with enclosed alternate flowpaths (i.e. conduits) that can provide a good distribution of gravel over the entire completion interval. The alternate flowpaths for the slurry are positioned in the annulus formed by the base pipe and the external surface of the screen, and connected to corresponding exit nozzle chambers positioned at different levels on the screen, and therefore do not significantly increase the overall effective outside diameter of the screen.

US Patent:

20050061501, Mar 24, 2005

Filed:

Sep 23, 2003

Appl. No.:

10/669079

Inventors:

Stephen Ward - Cypress TX, US
Terje Gunneroed - The Woodlands TX, US
Paul Vorkinn - Lillehammer, NO

International Classification:

E21B043/08

US Classification:

166278000, 166227000

Abstract:

Apparatus for gravel packing a wellbore interval with enclosed alternate flowpaths (i.e. conduits) that can provide a good distribution of gravel over the entire completion interval. The alternate flowpaths for the slurry are positioned in the annulus formed by the base pipe and the external surface of the screen, and connected to corresponding exit nozzle chambers positioned at different levels on the screen, and therefore do not significantly increase the overall effective outside diameter of the screen.

US Patent:

20050082060, Apr 21, 2005

Filed:

Oct 21, 2003

Appl. No.:

10/690306

Inventors:

Stephen Ward - Cypress TX, US
Terje Gunneroed - The Woodlands TX, US
Paul Vorkinn - Lillehammer, NO

International Classification:

E03B003/18

US Classification:

166278000, 166227000

Abstract:

A method for performing a gravel pack and/or frac pack by pumping down small tubes connected to nozzle chambers installed in the well screen in an open or cased hole of an oil, gas or water well. The well employs an open-hole wellbore adjacent to a substantial portion of an unconsolidated or poorly consolidated subterranean oil or gas reservoir. A well screen is located inside the open-hole wellbore forming an annulus between the open-hole and the well screen. One or more conduits are positioned in the annulus formed by the base pipe and the outer surface of the screen, and connected to corresponding exit nozzle chambers positioned at different levels on the screen. These are the primary conduits for the solids ladened fluid to be transported to the exit nozzles attached to the well screen member that provide fluid communication between the conduit and the annulus between the open-hole and the well screen. The solids ladened fluid is pumped to and out through the exit nozzles as the fluid dehydrates the solids (gravel) are deposited on the well screen as the fluid passes through leaving the annulus packed with gravel. This method is also applicable to gravel packing and/or frac packing in a cased wellbore with perforations for fluid communication between the cased wellbore and a substantial portion of an unconsolidated or poorly consolidated oil or gas reservoir.

US Patent:

20180291710, Oct 11, 2018

Filed:

Apr 3, 2018

Appl. No.:

15/943801

Inventors:

Vijay Rajkumar - Houston TX, US
Stephen Ward - Cypress TX, US
Phong Vu - Houston TX, US

Assignee:

Delta Screen & Filtration, LLC - Houston TX

International Classification:

E21B 41/00
B05B 15/18

Abstract:

Embodiments of an apparatus generally include a substantially “u” shaped cap comprising a nozzle, wherein the nozzle cap is adapted to be longitudinally positioned onto a shunt tube and welded thereto, thereby affixedly positioning the nozzle over a shunt tube opening to allow fluid to flow from the shunt tube interior through the nozzle via the opening. Additional embodiments generally comprise a substantially tubular sleeve comprising a nozzle, wherein the nozzle sleeve is adapted to be slidingly longitudinally advanced onto a shunt tube and welded thereto, thereby affixedly positioning the nozzle over a shunt tube opening to allow fluid to flow from the shunt tube interior through the nozzle via the opening. In various embodiments, some interior or exterior surfaces of the nozzle cap and/or the nozzle sleeve comprise an erosion resistant and/or low friction material. Methods of utilizing the nozzle cap and providing a nozzle sleeve assembly are provided.

US Patent:

20180266594, Sep 20, 2018

Filed:

Mar 12, 2018

Appl. No.:

15/918443

Inventors:

Stephen Ward - Cypress TX, US

Assignee:

Delta Screen & Filtration, LLC - Houston TX

International Classification:

F16L 21/03
E21B 17/04
F16L 21/08

Abstract:

Embodiments of an apparatus of the present invention generally include a tubular, substantially exteriorly rectangular, jumper tube connector having a substantially rectangular interior cavity having a plurality of transverse grooves disposed in the surface thereof and extending there around, wherein at least a portion of the jumper tube connector along its two opposing wide sides has a non-uniform wall thickness, at least a portion of which being thicker than a substantially uniform wall thickness of the connector's two opposing narrow sides. A method of connecting shunt tubes utilizing the apparatus is also provided.

US Patent:

20170204682, Jul 20, 2017

Filed:

Apr 4, 2017

Appl. No.:

15/478607

Inventors:

Stephen Ward - Houston TX, US
Steven Mark Everritt - Houston TX, US
Steven Camp - Houston TX, US
Vijay Rajkumar - Houston TX, US

Assignee:

Delta Screen & Filtration, LLC - Houston TX

International Classification:

E21B 17/046
E21B 19/16

Abstract:

Embodiments of a jumper tube connection assembly generally include a retention clip having beveled and locking surfaces, a retention clip frame, and a biasing means, wherein the clip is restrained partially within the frame and is pivotable in response to a jumper connector contacting the beveled surface during shunt tube engagement therewith, and wherein the biasing means positions the locking surface to prevent jumper connector reverse movement. Other embodiments generally include a retention clip having a locking component, a retention clip support, and a biasing means, wherein the clip is restrained partially within the support and is pivotable in response to force biasing the locking component away from a shunt tube during jumper connector engagement therewith, wherein upon force cessation the biasing means positions the locking component in engagement with a jumper connector orifice, thereby preventing disengagement thereof from the shunt tube. Methods of utilizing the embodiments are also provided.

US Patent:

20160356098, Dec 8, 2016

Filed:

Jun 1, 2016

Appl. No.:

15/169944

Inventors:

Stephen Ward - Houston TX, US
Steven Mark Everritt - Houston TX, US
Steven Camp - Houston TX, US

Assignee:

Delta Screen & Filtration, LLC - Houston TX

International Classification:

E21B 17/046
E21B 19/16

Abstract:

Embodiments of a jumper tube connector assembly generally include a jumper tube, one or more fasteners affixed to and biased toward the exterior thereof, and two connectors slideable thereon, wherein each fastener is biased against a connector exterior, whereby upon slidably engaging each connector with a shunt tube, biases cease and a fastener end surface prevents connector backsliding. Embodiments of a jumper tube connection assembly generally include a retention clip having a locking surface, or a pin-locking retention clip having a pin, wherein the retention clip/pin-locking retention clip is affixed to a shunt tube, wherein upon slidably engaging a connector therewith, reverse axial connector movement is prevented by the locking surface/pin. Embodiments of a leak-off tube retention system generally include a leak-off tube having one or more spring-loaded buttons and adapted to releasably engage upper and lower retainer fittings via orifices therein. Methods of using these embodiments are also provided.
