Stephen M Wilkinson

US Patent:

20170212164, Jul 27, 2017

Filed:

Jan 26, 2016

Appl. No.:

15/006977

Inventors:

- North Reading MA, US
Daniel A. Derringer - San Jose CA, US
Stephen R. Wilkinson - Gilroy CA, US

Assignee:

Teradyne, Inc. - North Reading MA

International Classification:

G01R 31/28
G01R 1/04
G01R 1/44
G01R 1/073

Abstract:

A tester interface unit comprising a test hardware module. The test hardware module may have a simple construction, relying on control and/or signal processing in one or more tester instruments to generate or analyze test signals for a device under test. The test hardware module may be disposed within the tester interface unit, providing a short and high integrity signal path length to the device under test. The tester interface unit may include a purge gas chamber and a cooling chamber, with the hardware module penetrate a separator between those chambers, sealing an opening between the purge gas chamber and the cooling chamber. A heat spreader may move heat generated on the portion of the test hardware module in the purge gas chamber to the cooling chamber.
