The present invention is a polishing pad conditioning head for a CMP and similar types of apparatus that is especially useful in conditioning the surface of fixed-abrasive CMP polishing pads to maintain optimal process conditions for the planarization process on dielectric and metal films on semiconductor wafers, as well as wafers and disks used in computer hard disk drives. The polishing pad conditioning head comprises a substrate and a layer of fine-grain chemical vapor deposited polycrystalline diamond that is bonded onto the substrate. Alternatively, a thin sheet of polycrystalline diamond may be deposited on a preferred growth substrate by a chemical vapor deposition process, then removed from the growth substrate and then bonded to the CMP conditioning disk substrate.
Chemical Mechanical Planarization System And Method Therefor
James F. Vanell - Tempe AZ Todd W. Buley - Mesa AZ
Assignee:
Motorola, Inc. - Schaumburg IL
International Classification:
H01L 21302
US Classification:
438691
Abstract:
A chemical mechanical planarization tool that reduces a volume of polishing chemistry used in a wafer polishing process includes a rinse bar (87) for removing polishing chemistry and particulates from a polishing media and a slurry measurement system (84) for regulating a pump (83) of a slurry delivery system. A volume of the slurry delivery system is reduced to less than 100 milliliters. Approximately a minimum volume of polishing chemistry for polishing a single wafer is dispensed during each wafer polishing process of a wafer lot. During each wafer polishing process the slurry delivery system is purged to prevent settling, agglomeration, and hardening of the polishing chemistry. The rinse bar (87) sprays a surface of the polishing media to remove spent polishing chemistry and particulates prior to polishing another semiconductor wafer.
Low-Pressure Chemical Vapor Deposition Process For Depositing High-Density Highly-Conformal, Titanium Nitride Films Of Low Bulk Resistivity
Gurtej S. Sandhu - Boise ID Todd W. Buley - Mesa AZ
Assignee:
Micron Technology, Inc. - Boise ID
International Classification:
H01L 21285
US Classification:
438681
Abstract:
A low-pressure chemical vapor deposition process is disclosed for creating high-density, highly-conformal titanium nitride films which have very low bulk resistivity, and which provide excellent step coverage. The process utilizes a metal-organic compound, tetrakis-dialkylamido-titanium Ti(NR. sub. 2). sub. 4, as the primary precursor, in combination with an activated species which attacks the alkyl-nitrogen bonds of the primary precursor, and which will convert the displaced alkyl groups into a volatile compound. Any noble gas, as well as nitrogen or hydrogen, or a mixture of two or more of the foregoing may be used as a carrier for the precursor. The activated species, which may include a halogen, NH. sub. 3, or hydrogen radicals, or a combination thereof, are generated in the absence of the primary precursor, at a location remote from the deposition chamber. The wafer is heated to a temperature within a range of 200. degree. -600. degree. C.
James F. Vanell - Tempe AZ Todd W. Buley - Mesa AZ
Assignee:
Motorola, Inc. - Schaumburg IL
International Classification:
B24B 5300
US Classification:
451 72
Abstract:
A chemical mechanical planarization tool that reduces a volume of polishing chemistry used in a wafer polishing process includes a rinse bar (87) for removing polishing chemistry and particulates from a polishing media and a slurry measurement system (84) for regulating a pump (83) of a slurry delivery system. A volume of the slurry delivery system is reduced to less than 100 milliliters. Approximately a minimum volume of polishing chemistry for polishing a single wafer is dispensed during each wafer polishing process of a wafer lot. During each wafer polishing process the slurry delivery system is purged to prevent settling, agglomeration, and hardening of the polishing chemistry. The rinse bar (87) sprays a surface of the polishing media to remove spent polishing chemistry and particulates prior to polishing another semiconductor wafer.
Name / Title
Company / Classification
Phones & Addresses
Todd Buley Manager
Rodel Inc Chemicals · Nonwoven Fabrics
3804 E Watkins St, Phoenix, AZ 85034 (602)4310500
Resumes
Director Global Applications, Electronics And Imaging, Cmp
Dupont
Director Global Applications, Electronics and Imaging, Cmp Technologies
The Dow Chemical Company
Global Applications Director, Product Placement
The Dow Chemical Company Apr 2008 - Sep 2014
Global Product Applications Development and Placement Manager
The Dow Chemical Company Nov 1999 - Apr 2008
Process Engineer
Motorola Apr 1994 - Nov 1999
Engineer
Education:
Devry University 1986 - 1990
Arizona State University 1985 - 1989
Bachelors, Bachelor of Science In Electrical Engineering, Electrical Engineering
Skills:
Semiconductors R&D Process Engineering Cvd Design of Experiments Product Development Cross Functional Team Leadership Process Simulation Root Cause Analysis Semiconductor Industry Manufacturing Materials Science Spc Engineering Six Sigma Cmp Polymers Thin Films Process Improvement Chemical Engineering Engineering Management Continuous Improvement Electronics Product Management Jmp Failure Analysis Characterization Global Leadership Technology Development Chemicals Application Management Application Development Semiconductor Design Semiconductor Manufacturing Semiconductor Equipment Software Development
