Todd Michael Visconti

US Patent:

20020064450, May 30, 2002

Filed:

Nov 29, 2000

Appl. No.:

09/725823

Inventors:

Stephen Coomer - Tempe AZ, US
Stanislaw Kopacz - Phoenix AZ, US
Glyn Reynolds - Gilbert AZ, US
Michael Lombardi - Phoenix AZ, US
Todd Visconti - Phoenix AZ, US

Assignee:

Tokyo Electron Limited

International Classification:

B65G049/07

US Classification:

414/939000, 414/941000

Abstract:
